BRC 10x10 6x6 concrete reinforcing welded wire mesh panel for building wall concrete reinforcement(factory price,size, weight)
BRC 10x10 6x6 concrete reinforcing welded wire mesh panel for building wall concrete reinforcement(factory price,size, weight)
BRC 10x10 6x6 concrete reinforcing welded wire mesh panel for building wall concrete reinforcement(factory price,size, weight)
BRC 10x10 6x6 concrete reinforcing welded wire mesh panel for building wall concrete reinforcement(factory price,size, weight)
BRC 10x10 6x6 concrete reinforcing welded wire mesh panel for building wall concrete reinforcement(factory price,size, weight)
BRC 10x10 6x6 concrete reinforcing welded wire mesh panel for building wall concrete reinforcement(factory price,size, weight)
BRC 10x10 6x6 concrete reinforcing welded wire mesh panel for building wall concrete reinforcement(factory price,size, weight)

BRC 10x10 6x6 concrete reinforcing welded wire mesh panel for building wall concrete reinforcement(factory price,size, weight)

Share on (60252494815):


Price:RUB 76.68 - RUB 766.76

Quantity:


Product Overview

Description

BRC 10x10 6x6 concrete reinforcing welded wire mesh panel for building wall concrete reinforcement(factory price,size, weight)





Product Description

BRC 10x10 6x6 concrete reinforcing welded wire mesh panel is extensively used in common concrete component and spot pour.



Also the concrete reinforcement wire mesh panel is used in the construction industry to network and GJ board partition net.Is  ideal material for high rize new construction.



It also used as concrete reinforcing for floor heating system to protect the heating pipe,reinforcing the concrete floor.

reincorcing welded wire mesh.jpgconcrete reinforcement wire mesh welded.jpg

Production process:

concrete welded wire mesh.jpg



Specification

Welded wire fabric (WWF) for concrete slab reinforcement

This type of concrete reinforcing welded wire mesh panel  is a square grid of uniformly placed wires,  welded at all intersections, and meeting the requirements of ASTM A185 and A497 or other standards.The sizes are specified by combining the spacing, in inches or mm, and the wire cross section area in hundredths of square inches or mm2. The common sizes are in the following table:

Material:steel wire,iron wire,stainless steel wire 304 316 201

Mesh: 6x6 10x10

Finishing:hot dipped galvanized,



Imperial Size

Metric Equivalent

Weight Imperial

Weight Metric

6x6 W1.4/W1.4

152x152 MW9.1/MW9.1

20 lb/100 sf

0.98 kg/m2

6x6 W2.1/W2.1

152x152 MW13.1/MW13.1

30 lb/100 sf

1.47 kg/m2

6x6 W2.9/W2.9

152x152 MW18.7/MW18.7

41 lb/100 sf

1.99 kg/m2

6x6 W4.0/W4.0

152x152 MW25.8/MW25.8

56 lb/100 sf

2.73 kg/m2

6x6 W5.4/W5.4

152x152 MW34.9/MW34.9

76 lb/100 sf

3.72 kg/m2

4x4 W1.4/W1.4

102x102 MW9.1/MW9.1

30 lb/100 sf

1.46 kg/m2

4x4 W2.1/W2.1

102x102 MW13.3/MW13.3

43 lb/100 sf

2.40 kg/m2

4x4 W2.9/W2.9

102x102 MW18.7/MW18.7

61 lb/100 sf

2.96 kg/m2

4x4 W4.0/W4.0

102x102 MW25.8/MW25.8

83 lb/100 sf

4.06 kg/m2

4x4 W5.4/W5.4

102x102 MW34.9/MW34.9

119 lb/100 sf

5.82 kg/m2

reinforcing welded wire mesh 20.jpgreinforcing welded wire mesh 21.jpg



Application

building wall concrete reinforcement,floor heating system,protecting fencepanels 7heating net

concrete reinforcement wire mesh 1.jpgconcrete reinforcement wire mesh welded.jpg







Packaging & Shipping

the BRC 10x10 6x6 concrete reinforcing welded wire mesh could be packed in roll or pannels depending on the wire diameters request.

WELDED WIRE MESH PANEL001

 welded wire mesh galvanized roll 1.jpg



packing of galvanized welded wire mesh
