Precise Colorimeter SC80 with PC software for data management

Product Overview

Description

Precise Colorimeter SC80 with PC software for data management



Key Features:

• Tolerance setting, auto-judge color difference values and color deviation make you judge the color easily even you don’t have any professional knowledge in color.


• Using professional color analysis software you can do the color data analysis and color difference diagrammatic outputting.


• Via optional mini printer the color data can be printed out on site.

Specifications

Model	SC80 Color Reader
Accuracy	0.08 (average value of 30 times @ the standard white tabula)
Lighting/Inspecting system	8/d (8o falloff/diffuse reflection) SCI (include flat mirror light)
Light source	White light source , halogen lamp
Inspection angle	10 degree angle of view in CIE
Inspection conditions	D65
Rectification	White board rectification Black board rectification
Storage	100 groups of standard samples, 100 groups of values for each sample
Display	L*a*b*, L*c*h*, ΔE*ab, XYZ, with respect to RGB, Δ(L*a*b*), Δ(L*C*H*) Whiteness: Hunter Whiteness, Ganz Whiteness Yellowness: Yellowness index
Language	English / Chinese
Aperture (mm)	Ø8
Power supply	4 pcs of alkaline batteries or nickel batteries special adaptor (DC, 5V)
Net weight (g)	550g
Dimension (mm)	77x86x210



Standard package
SC80/SC10 main unit 1
Standard white tabula 1
Standard black cavity 1
USB cable 1
Software CD 1
Power adapter 1
Operation manual 1
Bag(SC80 only) 1
Optional accessory
Micro Printer
