fully automatic biscuit making machine/biscuit production line

Product Overview

Description

fully automatic biscuit making machine/biscuit production line

Biscuit producing process

flour mixing/material conveying-------laminating------Forming--------soft biscuit forming----- Biscuit & waste separating/recycling/conveying to oven ------oil spraying-----baking, baked well from oven----belt-type sugar & salt sprinkling machine





Biscuit can be grouped into hard biscuit, soft biscuit, cookie biscuit, according to the formula, process and different forming method. Hard biscuit production line is generally, composed of a feeding machine(if producing the soda biscuit or chocolate coated biscuit, anther lamination process is needed), a set of dough roller, through the dough rolling and dough sheet, then through the roller cutting machine, rest material recycling device, inlet oven machine, the entire biscuit forming line, For soft biscuit and cookie biscuit production line, only the o\\forming machine and inlet oven machine can be the whole forming process, in order to increase the biscuit types and characteristics, customer can allocate the sugar& salt sprinkling machine, egg spraying machine, egg painting machine, calico printing machine, etc. The oven is to make the formed biscuit into delicious food. You can choose different types of bakery oven (Electricity/gas/diesel/thermal oil) for baking different types of products. Dough rolling width is 250mm to 1200mm (if you have special needs, we can customize for you).



 Main parameters

model	KH-BGX250	KH-BGX400	KH-BGX600	KH-BGX800	KH-BGX1000	KH-BGX1200
Production capacity	100KG/h	250 KG/h	500 KG/h	750 KG/h	1000 KG/h	1250 KG/h
Total length	29600	64500	85500	92500	125000	125000
Baking temperature	190-240℃	190-240℃	190-240℃	190-240℃	190-240℃	190-240℃
Whole line power	65KW	190KW	300KW	380KW	700KW	830KW
Whole line weight	6000	12000	20000	28000	45000	45000
