black paint load scope 0.2ton 50ton baldt stockless anchor
- Category: >>>
- Supplier: Qingdao Rainar Int`l Trade Co. Ltd.
Share on (60258553726):
Product Overview
Description
0.2ton --50ton baldt stockless anchor
Product Description
Our products include anchor, anchor chains,(diameter from 12mm to 122mm), accessories, mooring equipment. We employed a selected group of dedicated personnel who are committed to supplying quality products by professional service, so our products are of superior quality .
If you have plans to purchase anchor or anchor chains, please do not hesitate to get in touch with me. We endeavour to supply the best available products at the best prices for you.
We look forward to your enquiry!
baldt stockless anchor size table:
| weigh | open mouth | max width | max height | max thickness |
| kg | mm | mm | mm | mm |
| 250 | 145 | 510 | 680 | 278 |
| 300 | 155 | 560 | 730 | 300 |
| 625 | 195 | 725 | 900 | 380 |
| 750 | 205 | 770 | 965 | 415 |
| 1000 | 235 | 854 | 1068 | 456 |
| 1200 | 250 | 900 | 1170 | 470 |
| 1500 | 265 | 1000 | 1320 | 508 |
| 1720 | 298 | 1054 | 1320 | 533 |
| 2000 | 320 | 1157 | 1460 | 625 |
| 2500 | 320 | 1157 | 1473 | 591 |
| 3000 | 326 | 1210 | 1504 | 620 |
| 3500 | 326 | 1210 | 1626 | 699 |
| 4000 | 350 | 1300 | 1740 | 716 |
| 5000 | 375 | 1400 | 1804 | 768 |
| 6000 | 456 | 1600 | 2016 | 870 |
| 7000 | 465 | 1660 | 2083 | 870 |
| 8000 | 463 | 1683 | 2375 | 870 |
| 10000 | 490 | 1810 | 2438 | 1000 |
| 12500 | 525 | 1920 | 2424 | 1016 |
