long life 1600 double spiral type sic heating elements With High Temperature

 Specifications

1.Heating temperature: 600-1600C
2. Diameter: 8-54mm
3. Length: 240-4000mm
4. Material: Good quality green SiC powders

Rod type silicon carbide heating elements are made from high-density, high-purity silicon carbide, which is the most popular type of economical heating element capable of operating under hot and rigorous environments.

Features:

1. Withstands as high as 1600°C (surface temperature),

2. Generates high heat output per unit surface area, approximately 5-10 times than the output of Nichrome wire,

3. High strength and excellent shock resistance,

4. Heat source is free of noise and air pollution.

It is used in various high temperature electric furnaces and other electric heating devices, such as in the industries of magnet, ceramics, metallurgy, glass, and machinery.

Physical properties of SiC heating elements:

Recommend surface load:

Detailed introduction:

Rod type SiC heating elements is kind of non-metal high temperature electric heating element.it is made of selected super quality green silicon carbide as main material,which is made into black, silicon under high temperature and re-crystallized.Compared with metal electric heating element,this kind of element is characterized by high-applied temperature,anti-oxidezation,anti-corrosion,long service life,little deformation,easy installation and maintenance,Therefore it is widely used in various high temperature electric furnaces and other electric heating devices,such as in the industries of magnet,ceramics,power metallurgy,glass,metallurgy and machinery,etc

We adopt new production process of cold ends so that our SIC heating elements have more excellent specific rate of heat zone resistance and cold end resistance,saving energy,long life,avoiding over-temperature of cold end to damage the furnace body,the commercial name of our sic heating elememts is silca heating elements.

When you place order,pls tell us the following data:

1)Outer diameter(OD):mm

2)Length of Hot zone(HZ):mm

3)Length of Cold end(CZ):mm

4)Length of Overall(OL):mm

5)Shank spacing(A):mm

6)Resistance(at 1050C+/-50C):ohms

 Product Produce Show:

Why choose us?

1. Why the price is so low?
 You are ordering to the direct factory.

2.Where is your factory located? How can I visit there?

Our factory is located at the 10km southeast of the world-known ancient temple-Shaolin temple, it enjoys a beautiful environment, wonderful scenery and convenient transporation.

It is  in Dengfeng City, HenanProvince, China.

3.What type of payment do you have available?
A: TT and L/C,

B: West Union,Money gram and Escrow are available for sample order.

4.How can I get some samples?

We are honored to offer you samples.

5.How does your factory do regarding quality control?

As for Quality, without compromise, Jinyu always attach great importance to

quality controlling from the very beginning to the very end.

 With fine production equipment,advanced production process and complete testing devices as well as a group of high-evel engineers and specialists,our company researches and develops mainly the thermoelectric material products:series products such as siliconit,silicon molybdenum rod ,tungsten and molybdenum materials and their products,of which,the siliconit has several varieties with nearly 1000 specifications such as  equal diameter rod,thick end rod,spear rod,U-type rod ,W-type rod,and allotype rod.We have all them adhered to the tenet of survival by quality,development by reputation,and perfect service ad flexible operating method to serve numerous businessmen both from home and abrond

Company idea:take people as base,be practical and realistic,keep improving,and pursue excellence
