Ремешок с храповым механизмом
- Category: Ratchet Tie Downs >>>
- Supplier: Jiangsu Xingzhou Industrial And Mining Equipment Co. Ltd.
Share on (60265015299):
Product Overview
Description
Rope Ratchet Tie Down Strap
Item No. | RTD Series |
| Features | - Ratchet + Webbing + Ending Fittings - safe factor 2:1 - Ratchet Handle/Hook: Plastic handle/Double J Hook - Ratchet/Hook color: Yellow Zinc Plated - Webbing Color: Yellow/Orange/Blue - BS: 5000Kg/11000Lbs |
| Performance | Bundle and tie down the good during transport |
| MOQ | 1 unit |
| Warranty | 1 Year |
| Payment | L/C, T/T, Western Union |
| Packing Details | Iron Pack |
The ratchet tie down device is applied to bundle and tie down the good during transport and trail car self-help service. The ending fitting can be equipped by different requirements, such as double hook, triangle ring, etc. The safe factor of the ratchet tie down is 2:1. Please note that this device cannot be used in lifting goods.
Tenical Parameter(For Reference Only)
There are different types of ratchet tie down. We can design and produce the width, length of the strap and applicable ending fittings according to your specific application.
Type 1
Product No. | Breaking Load | Strap Width | Whole Length | Whole Weight |
XT01-015 | 1500 | 25 | 8 | 1.25 |
XT01-03 | 3000 | 38 | 8 | 2.10 |
XT01-05 | 5000 | 50 | 8 | 2.90 |
XT01-08 | 8000 | 75 | 8 | 7.40 |
Type 2
Product No. | Breaking Load | Strap Width | Whole Length | Whole Weight |
XT02-015 | 1500 | 25 | 8 | 1.00 |
XT02-03 | 3000 | 38 | 8 | 1.45 |
XT02-05 | 5000 | 50 | 8 | 2.21 |
XT02-08 | 8000 | 75 | 8 | 5.40 |
Type 3
Product No. | Breaking Load | Strap Width | Whole Length | Whole Weight |
XT03-015 | 1500 | 25 | 8 | 1.05 |
XT03-03 | 3000 | 38 | 8 | 1.60 |
XT03-05 | 5000 | 50 | 8 | 2.33 |
XT03-08 | 8000 | 75 | 8 | 5.60 |
Type 4
Product No. | Breaking Load | Strap Width | Whole Length | Whole Weight |
XT04-015 | 1500 | 25 | 8 | 1.10 |
XT04-03 | 3000 | 38 | 8 | 1.70 |
XT04-05 | 5000 | 50 | 8 | 2.62 |
XT04-08 | 8000 | 75 | 8 | 6.40 |
