Industry drinking RO Underground water filter system tap water/river water/lake water filter

Product Overview

Description

 Industry drinking RO Underground water filter system tap water/river water/lake water filter



Challenges in Food and Beverage industry

Water is one of the first ingredients used when manufacturing food,as process water for beverages,ready meals or dairy products.It is also a processing aid used throughout the process(cleaning water,transport water),as well as an energy utility when used as steam or for refrigeration(boiler feed water,cooling water,ice for preservation).The production of specification quality water for the process and treatment of resulting wastewater are crucial activities in the food industry.



Improving your water quality while meeting regulations

Municipalities are faced with growing populations, a decrease in available fresh water supplies, and more stringent regulations. Food production sites must now comply with numerous requirements in the hygeian, economic and environmental domains. Cities worldwide are turning to Molecular’s drinking water treatment solutions to help optimize resources and  provide high-purity water to their residents. Molecular reverse osmosis system is ready to help you promote food safety and achieve regulatory compliance.



Molecular reverse osmosis system technology can

♦Meet the increased water demands of a growing population and overcome water scarcity issues
♦Treat challenging source water while meeting or exceeding regulatory requirements
♦Deliver high performance water purification at the lowest life-cycle costs
♦Address your water needs within your current plant footprint
♦Reduce operational costs, enhance product quality as well as boost the brand perception





Advantages of  Reverse osmosis water purification system/reverse osmosis



1.Runs automatically and controlled by PLC(economical manual operation for your option)
2.Protection system, plant turns off if it encounters a fault
3.Energy saving and low noise, no need to heat
4.Stable running, high desalination and recovery rate with no pollution
5.Compact structure and saves installation place
6.Easy to operate, wash RO membrane when turn on and off
7.Dependable performance and long life time
8.Highly efficient and low carbon emissions





Parameter List:



Model	Capacity(M3/H)	Diameter	Mpa	Material	Technology
MOLFB-0.25	0.25	Dn20	≤ 1.0	Stainless steel/carbon steel	full-automatic/semi-automatic
MOLFB-0.5	0.5	Dn20	≤1.0	stainless steel/carbon steel	full-automatic/semi-automatic
MOLFB-1	1	Dn25	≤1.0	stainless steel/carbon steel	full-automatic/semi-automatic
MOLFB-2	2	Dn32	≤1.0	stainless steel/carbon steel	full-automatic/semi-automatic
MOLFB-3	3	Dn40	≤1.0	stainless steel/carbon steel	full-automatic/semi-automatic
MOLFB-5	5	Dn50	≤1.0	stainless steel/carbon steel	full-automatic/semi-automatic
MOLFB-10	10	Dn75	≤1.0	stainless steel/carbon steel	full-automatic/semi-automatic
MOLFB-20	20	Dn100	≤1.0	stainless steel/carbon steel	full-automatic/semi-automatic
MOLFB-30	30	Dn125	≤1.0	stainless steel/carbon steel	full-automatic/semi-automatic
MOLFB-40	40	Dn150	≤1.0	stainless steel/carbon steel	full-automatic/semi-automatic
MOLFB-50	50	Dn200	≤1.0	stainless steel/carbon steel	full-automatic/semi-automatic
Note: 1. Our system is customized, we can provide best solution according to your requirements.       2. The products model are not all listed in this table. For more items, please consult Molecular Water System’s sales engineer.





Design requirement

No.	Items	Parameter specification
1	Parameter of raw water	Reservoir water, underground water, etc
2	Produced water index	Conform to Standards for Drinking Water Quality GB5749-2006
3	Other requirements	Integrated skid-mounted structure, enclosed type, open doors at the sides,    the supplier provides the trailer, the client prepares the generator, fuel tank       and the headstock



Flow Chart:

Water intake point→ Lift pump→ Cyclone desander→ Quartz sand filter → Activated carbon filter→ Scale inhibitor feeding device→ Security filter→ High pressure pump→ RO device→ Drinking water tank→ Delivery pump→ UV sterilizer→ Water consuming point





Specification of equipment

No.	Items	Parameter specification
1	Name	4T/H mobile vehicle water purifying equipment
2	Model	MOLEFW-4000L
3	Water production	4T/H
4	Water quality of outlet water	Conform to Standards for Drinking Water Quality GB5749-2006
5	Stable desalination rate	Reverse osmosis desalting rate:  >98% within one year; >96% within three years
6	Process	Lift pump→ Pre-treatment→ Reverse osmosis host→ Water consuming point
7	Recovery rate of system	Recovery rate of RO: 50-75%

8	Control method	Full automatic + manual
9	Total power	Total power of operation: 15 KW



More detailed information, pls just let me know!





Products we made for customers















Delivery period and after-sale service

1. Time of delivery: deliver in 80 calendar days after signing the contract.
2. The warranty period is 12 months, which will be calculated from the date that the equipment is tested to be qualified. During the warranty time, we will maintain all element of the system, excluding the normal replaced consumables; after the warranty, we will supply parts and consumables to client in a timely manner and also give some discounts to our client.
3. Our company guarantee the design is in accordance with client’s requirement, after the installation, our company also guarantees the performance, technical index of equipment conform to design requirement and also ensure the reliability after the equipment is put into operation.
