Product Description
Foam mixer foam generator for fire foam system with ISO, CCC Certificates
concrete foam generator high foam generator foam generator for foam concrete
1.Brief information
Designed as air aspirating discharge devices, foam generator is used principally for the protection of dikes, open floating-roof storage tanks, and rim seals, where low-velocity foam streams are desired. Foam generator generally is installed in the line of a semi-fixed or fixed foam fire-protection system, mounted either horizontally or vertically.
Foam generator's feature of all-brass construction is for using in harsh and corrosive environments. Foam generator air inlets is covered with stainless mesh, and supplied with standard NPT threaded inlets and outlets.
Minshan foam generator is horizontally fixed at the top of the tank wall, and it's a foam extinguishing equipment producing and jetting air. Foam fire truck or a fixed fire pump supply the mixture flow through the pipeline throught the bubble generator, and format the air bubble to put out oil fire. Foam generator is mainly composed of air bubble generator body, foam nozzle and guide group. When foam mixture liquid throught the foam generator nozzle, atomizing jet diffussion and produce negative pressure in its surrounding thus inhalation air to create foam, the foam liquid flow directly to the surfance of fire through guide group, cover the surface of liquid using bubble cooling to put out the fire.
2.Technical parameters
| Size | Working pressure Mpa | Rate flow mixture liquid(L/S) | Foam expansion | Flow series (k) | Inlet flange | Outlet flange | Height (mm) |
| PCL4 | 0.3-0.6 | 4 | ≥5 | 107 | 50 | 65 | 155 |
| PCL8 | 8 | ≥5 | 215 | 65 | 80 | 160 | |
| PCL16 | 16 | ≥5 | 429 | 100 | 125 | 185 | |
| PCL24 | 24 | ≥5 | 644 | 125 | 150 | 200 |
Product Image
Hot Selling Products
 |
 |
 |
 |
Factory View
Our Services
Primary Competitive Advantages:
1.Our company has several years's experience in producing all kind of forged brass ball valve and fittings , we have the self-operated importing and exporting rights .
2.Our products are approved by ACS ,CE ,ISO9001/14001 approved.
3.We can produce the fire fighting products according to our customer's requirement,and if the order is large , we don't charge any mould fee.
4. We insist to popularize our brand"Minshan" to our customers , and welcome to become our sales agency , We'll give our customer the special prices once the customer become our approved agency .
Outstanding Service:
Fast feedback: we promise to reply your inquiry within 24hours
Positive cooperation with your esteemed company
Good suggestions to your choice if necessary with our own rich experience
OEM accepted
Your visited to factory welcomed!
FAQ
Q:Are you a factory or trading company?
We are factory specialized on fire fighting equipment.
Q: Can I get a sample?
For certainly, please contact us for detail.
Q:What's the terms of the payment?
T/T, L/C, Western Union, MoneyGram, etc.
