JC Mini Aluminum Melting Furnaces Electric Crucible Furnace

Product Overview

Description

JC Mini Aluminum Melting Furnaces Electric Crucible Furnace

Specifications

JC Melting Furnaces

Mini Melting Furnaces

Aluminum Melting Furnaces

Mini Aluminum Melting Furnace

Mini Electric Aluminum Melting Furnaces

1.Product Description

JC Mini Aluminum Electric Crucible Melting Furnace is the best choice for melting gold,copper, silver and other noble metals, metallurgy, petroleum , chemical, Laboratory, heat-treatment.



Specifications

1.Voltage:110/ 220V



2.Frequency:50/60HZ



3.Capacity:1kg 2kg 3kg 4kg



4.Weight:9kg



5.Packing Size:29*33*47cm



6.Maximum Temperature:1200 C



7.Furnace Accessories:one crucible,one crucible tong,one heat insulating glass and glove,one replacement refuse and one manual instruction



8.Melted Metal:Aluminum, Copper, Gold, Lead, Silver, Sterling Silver, Tin & Zinc





2.Mini Aluminum Electric Melting Furnace Advantages

1). Exquisite & Convenient:

   Small size(170x220x370mm), light weight(N.W.:4.5KGS), independent operation,and portable.

2). Easy operation:

  The parameters can be changed conveniently by pressing arrow buttons.

  The setting temperature and surveyed temperature can be shown at the same time.

3). Accurate temperature control:

  Microprocessor PID control, PID auto-tuning function ensure the accuracy of the temperature control in any state

4). High efficiency:

  Fast heating, high efficiency, good insulation effect, low power

3.Technical Parameters

MODEL	Acceptable(kg)	Crucible Dim.(Øxh)(mm)	Power (kW)	Weight (kg)	Heating Speed (mins)
JC-K-110-1  (110V 1Kw)	1-3KG	Ø38X115	1	4	25-30
JC-K-110-2  (110V 2Kw)	1-3KG	Ø44X140	2	4.3	15-20
JC-K-220-1 (220V 1Kw)	1-3KG	Ø50X150	1	4.8	25-30
JC-K-220-2 (220V 1.5Kw)	1-3KG	Ø60X121	1.5	5	15-20

4.Accessories

1-1kg graphite crucible

1-crucible tongs.

1-replacement fuse.

1-insulating heat glasses.

1-gloves.

5.Production Line

6. Professional Certification
