Semiconductor Manufacture SEMI 6 8 12 Inch Wafer Dicing Ring
Application
Semiconductor Laboratory Equipment
Customization
Accepted
Material
Stainless Steel Monocrystalline Silicon Wafer
Size
6",8",12"
Surface
Lapping
Model Number
YJF-8
inch
A(mm)
R(mm)
r(mm)
T(mm)
hardness
flatness
surface treatment
6
212
228
194
1.2
HRC47 the above
0.2mm or less
BA & HL
8
276
296
250
1.2
HRC47 the above
0.2mm or less
BA & HL
12
380
400
350
1.5
HRC47 the above
0.3mm or less
BA & HL
Q: How do you reach our company?
A: After you confirm the time with us, please go to Taiwan Taoyuan International Airport by airplane; afterward, we will appoint our staff to take you; our company is just in Taoyuan City.
Q: How do you provide the quotation?
A: EXW FOB CIF.
Q: Are you our manufacturing factory?
A: Yes, we are the professional manufacturing factory of stainless-steel products; we were founded in 1983 and well-experienced. We keep purchasing new machines to enhance our production ability.
Q: Do you provide OEM or ODM service?
A: Yes, we provide both OEM service and ODM service. Please do not hesitate to contact; we look forward to providing service for you.
Q: Can you provide the product samples for us?
A: Yes, we can provide samples for most products except some special models.
Q: How do you package the products?
A: We will add the crash protection to different products, and we will use the paper box with 5 wave layers to package the outermost layer of the package.
Q: Can you provide the material quality certificate for us?
A: Yes, we will provide the material quality certificate for you; the material does not include mercury and the test report proves the material does not be contaminated by radiation; the test items include component analysis, tensile test, hardness test and the like, which are based on JIS standard.
