This machine is special designed for making kinder joy egg with chocolate, biscuit and toy automatically.
2) Working Process:
Plastic Sheet (PET/PVC/HIPS) Heating----Egg Tray Thermoforming---Honey/Jam/Chocolate Filling ----AluminumFoil/Plastic Film Hot-Sealing---Impress---Servo Traction---Cutting---Transport Final Product Out Automatically.
3)Main Technical Parameter:
Model
DPB-400B
Running Speed
20-30 cycles/min
(If the forming height is more than 26mm, the speed will be lower)
Max. Forming Area
400x180mm
Max. Forming Depth
25mm (can desigend to 50mm)
Stroke
40-180mm
Air Pressure
0.4-0.6MPa
Air Consumption
0.3m³/min
Heating Power
2.5KW*3pcs=7.5KW
Main Motor Power
2.2KW
Lower Film Material (Rigid Film)
PET, PVC, PS Sheet
Lower Film Material Thickness
0.15-0.5mm x 410mm
Upper Film Material
Aluminum foil(PTP): 0.02-0.035mm x 410
Dialysis Paper: 50-100g x 410mm
Upper Film Material Thickness
0.06-0.08mm
Power Voltage
380V/50HZ
Machine Dimension
4500x820x1600mm(L/W/H)
Machine Weight
3000kg
Samples:
Video Link:
DPB 400B Chocolate & Biscuit Blister Packing Machine Car Shape:
https://www.youtube.com/watch?v=KyxcX2kuJtk
Manufacturer of Automatic Chocolate Blister Packing Machine:
https://www.youtube.com/watch?v=0-JSJkub_JE
Automatic Kinder Joy Egg Production Line:
https://www.youtube.com/watch?v=oqQjF-WVrHM
Big Kinder Joy Egg Blister Packaging Machine Spider-man:
