Single head cutting saw aluminum window machine

Product Overview

Description

Single head cutting saw aluminum window machine

Single Head Up Cutting Saw LJZG-500







Specification
1. LJZG-500 is Single head up Cutting saw with dia. 500mm saw blade

2. Cut profile from bottom to top
3. with Roller support and Stop Gauge system

   a. Mainly used for cut off the wide Aluminum Profiles

   b. The TCT saw blade for the diameter as big as dia.500mm as well as high speed and high cutting   precision.

   c. The saw blade can swing to required angle between 90° and 45 °.

   d. The saw blade cut the profile from bottom to top safely and reliably, and the cutting height and        width is enough.



Technical Parameter



Saw cutting (width*height)	240*150mm in 90 ° /240*130mm in 45 °
Main motor power	2.2KW
Main motor rotation speed	2840r/min
Saw blade dimension	Ø 500*Ø30*Ø120T
Saw blade swing angle	90° - 45°
Saw blade feeding speed	0-3m/min
Air pressure	0.6~0.8Mpa
Working voltage	3phases 380volts and 50hz.
Over all dimension (L*W*H)	5000(include the roller support)*1300*1500mm
Weight	1000kg
