Doosan Ingersollrand P250/HP185 Air Compressor 185CFM 250CFM At 7 10bar pressure Deutz diesel engine USA Origin
- Category: >>>
- Supplier: Shanghai Souair International Trade Co. Ltd.
Share on (60274932745):
Product Overview
Description
Doosan Ingersollrand P250/HP185 Air Compressor 185CFM-250CFM At 7-10bar pressure Deutz diesel engine USA Origin
Model: P250/HP185WDZ-T4F
Free Air Delivery: 185cfm -250cfm
Pressure: 7-10bar
The Tier 4F compliant P250/HP185WDZ portable air compressor produces 250 cfm at 100 psi, or 185 cfm at 150 psi making it ideal for countless applications, including general construction, sandblasting, pneumatic tool operation and pipeline testing.
P250/HP185WDZ-T4F Air Compressor
Powered by a Tier 4F-compliant Deutz Turbo engine, and engineered with DOC emissions technology, the P250/HP185WDZ portable air compressor offers compact, zero-maintenance engine after treatment design and maximizes jobsite productivity. With the ability to operate in dual modes offering 250 cfm at 100 psi, or 185 cfm at 150psi while also offering a seven-hour runtime at 100 percent load in either mode. The P250/HP185WDZ-T4F also sets forth a new industry leading technology for cooling the air compressor package with four electric fans providing a super quiet operation, (69 dBa in the low pressure setting and 73 dBa in the high pressure setting).
P250/HP185WDZ-T4F Air Compressor
COMPRESSOR
LOW PRESSURE
Free-Air Delivery – cfm (m3/min)250 (7.0)
Rated operating Pressure – psig (bar)100 (6.9)
Pressure range – psig (bar)80 - 175 (5.5 - 12.1)
Air Discharge outlet size – in (mm)0.75 (19.0)
Air Discharge outlet Quantity2
Fuel Tank Capacity – gal (L)27 (102)
ENGINE
Make/modelDeutz TD2.4
Emissions Tier LevelTier 4 Final (T4F)
Number of Cylinders4
Displacement – cu in (L)177 (2.9)
Rated speed – rpm2400
Idle speed – rpm1700
Bhp @ rated speed (kW)74 (55.2)
Electrical12
Hours of operation @ Full Load7.2
DIMENSIONS w/ running gear
Length – in (mm)142.5 (3620)
Width – in (mm)68.5 (1740)
Height – in (mm)67 (1701)
Track Width – in (mm)59 (1499)
Tire size – in15
Shipping Weight – w/o fuel – lb (kg)2610 (1184)
Working Weight – w fuel – lb (kg)2813 (1276)
DIMENSIONS w/o running gear
Length – in (mm)93.5 (2375)
Width – in (mm)49.3 (1252)
Height – in (mm)55.4 (1406)
Shipping Weight – w/o fuel – lb (kg)2386 (1082)
Working Weight – w fuel – lb (kg)2589 (1174)
