Doosan Ingersollrand HP450/VHP400Air Compressor450CFM 400CFM At 10 14bar pressure WCU diesel engine USA Origin

Product Overview

Description

Doosan Ingersollrand HP450/VHP400 Air Compressor450CFM-400CFM At 10-14bar pressure WCU diesel engine USA Origin

Model: HP450/VHP400WCU-T4i

Free Air Delivery: 450 cfm (12.7 m³/min) /

400 cfm (11.3 m³/min)

Pressure: 150 psig (10.3 bar) /

200 psig (13.8 bar)

The two-in-one HP450/VHP400WCU-T4i dual pressure portable air compressor delivers airflow ranging from 400 to 450 cfm and pressures ranging from 150 to 200 psi. With no increase in dimensional size from previous compressor models offered by Doosan Infracore Portable Power, users in a variety of markets will appreciate the small footprint. The compact size and a less running gear option allow the unit to be mounted on truck beds for increased flexibility. They are ideal for use in a variety of applications, including general construction, abrasive blasting and pneumatic tool applications.

HP450/VHP400WCU-T4i Air Compressor

Powered by Tier 4i-compliant Cummins engine and engineered with DOC emissions technology, the HP450/VHP400 portable air compressor offers compact, zero-maintenance design with no regeneration cycles.



Among the newly redesigned components on this model is the Mid-Port full gauge control panel. Standard on the panel is a tachometer display that allows the operator to see the selected engine and airend temperatures and pressure, as well as percentage of fan speed and engine load. The operator can set service intervals, languages and display features, for an improved operator interface.



Also included on the Mid Port control panel is a switch that allows the operator to easily change the pressure setting during compressor operation. The dual pressure feature can create either low airflow with high pressure or low pressure and high flow.



Service points are easily accessible without removing the canopy, along with simplified wiring and piping that also contributes to ease of servicing. Automatic shutdowns, relative to several critical operational parameters, help to avoid costly damage and subsequent repairs.

HP450/VHP400WCU-T4i Air Compressor
