alibaba express P10 outdoor single color led display board

Product Overview

Description

P10 outdoor waterproof single color led display alibaba express





The technology parameter of P10 single color outdoor
Number	Item	P10
1	Pixel pitch	10mm
2	Size of modual	160mm X 320 mm
3	Resolution of modual	16 X 32
4	Density of pixel	10000dots/m2
5	Pixel configuration	red &green&blue
6	Red wavelength	625±2nm
7	Green wavelength	525±2nm
8	Blue wavelength	470±2nm
9	Best viewing distance	10-120m
10	Horizontal viewing angle	120°
11	power consumption	200w/m2
12	Brightness	≥2500cd /m2
13	Gray scale	16bits per color
14	Color temperature	6500k
15	Control method	Synchronization & Asynchronization
16	Driving method	1/8 or 1/4scanning
17	Frame frequency	60Hz
18	Refresh frequency	≥300Hz
19	Working voltage	AC220V/110V±10%
20	IP grade	IP67(adjustable)
21	Working temperature	-20°C~80°C
22	MTBF	>10000 hours
23	Life span	>100,000 hours
24	Defects rate.	≤0.00001(Led display line standard<0.0001)











Package: Carton box/Wooden case/Flight case optional



Our service
1.Your inquiry related to our products or price will be replied in 24hrs
2.OEM&ODM,any your customized lightings we can help you to design and put into product
3.Distributoership are offered for your unique design and some our current models
4.Protection of your sales area,ideas of design and all your private information
5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win

6. our engineer will be on your service.We can give you technology support at any time.

7. We will be tracking your orders, from the pre-sale to the after-sale and also serve you in this process.

8.We can send our engineer to install the screen freely if you requested.



Trade Terms
1.Payment:L/C,western union,Paypal.T/T,30% deposits before production,70% balance to be paid before deliverying.ETC.
2.Shipping freight are quoted under your requests
3.Shipping port: Shenzhen, Mainland China
4.MOQ:1sqm
