En12209 CE certificate FIRE rated mortise lock 5085Z
5085Z
Parameter
Backset
50mm
Center distance
85mm
Fire test-Timber fire door
111 mins
Fire test- Steel fire door
260 mins
CE certificate (Intertek)
3 X 9 1 0 G 3 B C 2 0
Product Information
Intended Use
Yes/No
Comments
Reference
On hinged doors
Yes
Locks are tested for side force and end force
EN12209:2016
Supported lock application
Yes
Tested in accordance with 5.5.1 and 5.11.3 using the fixture 20 or 29 and/or 5.11.5 using fixture 32 with support
Suitability for use on smoke control /fire resistance doorset
Yes
See manufacturers declaration referring to a test according to EN 1634–1 or declaration of melting point of the relevant latching parts and if applicable the duration of the proven smoke control and/or fire resistance
Lock for use with unsprung handle
Yes
The lock shall conform to 5.4.6, minimum follower restoring torque of 0,8 Nm
CE Certifications
Installation Instructions
Packing&Shipping
1PC/BOX, 20PCS/CTN, 1000PCS/PALLET
Product Testing
Durability test (Hinge)
Durability test (Mortise lock)
Test temperature
Durability test (Handle)
Durability test(Cylinder)
Corrosion resistance
Company Introduction
HANRUI company has 260 workers which covers 30,000 square meters, specialize in Architectural hardware for fire doors (Mortise lock / Lever handle / Profile cylinder / Hinge).
We have passed Quality Management System: ISO9001:2015; Fire rated Products have got relevant CE certification \ Fire test and Performance certification.
1. Mortise lock have CE certification according to EN12209 and EN1634-1
2. Hinge have CE certification according to EN1935 and EN1634-1
3. Brass profile cylinder has been verified according to EN1303
4. Lever handle has been verified according to EN1906
We have our own workshops \ own funds and stable production & management team.
To realize Manufacture and Creation, we continue to improve equipment automation.
