Wenzhou high temperature limit switch resisting high heat
Saipwell Multi European wall socket / European combination switched socket
Limit switch Introduction:
Saipwell brand limit switch use high temperature resistant material as the interior fully sealed contacts. Its maximum allowable current is 5A/AC 220V. After special treatment to the contacts, Saipwell brand limit switch can be used in high temperature environment for a long time, without being oxidized or polluted. It can resist high temperature up to 350°C.
Saipwell brand limit switches are widely used in electric power, chemistry industry, petroleum, texitle and steel industry.
Product Show:
Cheap and good quality European 8 gang wall switch
Tehchnical Datas:
Rated voltage
Nonelectrical load
Electrical load
Resistance oarry
Bulb load
Electrical
Motor load
load
Contact Tyep
NC
NO
NC
NO
NC
NO
NC
NO
125VAC
10
3
1.5
10
5
2
250VAC
5
2
1
5
3
1
480VAC
3
1.5
0.8
3
1.5
0.8
600VAC
1
1
0.5
1.5
1
0.5
8VDC
10
6
3
10
6
14VDC
10
6
3
10
6
30VDC
6
4
3
6
4
125VDC
0.8
0.2
0.2
0.8
0.2
250VDC
0.4
0.1
0.1
0.4
0.1
Remarks:1.Electrical load:power factor=0.4.time constant= 7 msec. 2.The Bulb load current is 10 times as than in stable condition. Motor load current is 6 times as than in stable condition.
Dimension Drawing e
ap nd good quality European 8 gang wall switchuro Cheap and good quality European 8 gang wall switch
Packaging & Shipping
euro Cheap and good quality European 8 gang wall switch
Certifications
euro Cheap and good quality European 8 gang wall switch
Cetification :
Saipwell Multi British wall switch / combination switched socket
