Product Overview
Description
thermal silicone Adhesive Glue for pcb
Product Description
| Product Information |
| Product Name | Non-Corrosive Instant Adhesive Super Glue | |
| Item No. | US-511H | |
| Color | White,black,grey paste | |
Dry on surface(min) | 3-20 | |
| Hardness(JISA) | 45-55 | |
| Certificate | UL94 V-0 | |
| Tensile Strength(kgf/m2) | >15.0 | |
| Bonding strength(kgf/m2) | >17.0 | |
| Volume Resistivity (Ω) | >2.0*1015 | |
| Voltage(kv/mm) | 3.0 | |
| Breakdown voltage(kv/mm) | 20-25 | |
| Dielectric Constant(60Hz) | 3.0 | |
| Density(g/ml) | 1.45 | |
| Introduction | US 511H is one-component neutral cure silicone, channelled through condensation reaction with moisture in the air caused by low molecular cross-linking, then sulfide into high performance elastomer.After curing, the elastomer has excellent electrical properties, ageing resistance, resistance to high and low temperature (60 ~ 250)aa, insulation, moistureproof ,no swelling, has good adhesion for the majority of metal and nonmetal materials.Does not produce corrosion to the adhesive materials and do not prollution to the surrounding environment, comply with ROHS, UL94V-0 certification. | |
| Features and Benefits | After curing, the elastomer has excellent electrical properties, ageing resistance, resistance to high and low temperature (60 ~ 250)°C, insulation, moistureproof ,no swelling, has good adhesion for the majority of metal and nonmetal materials.Does not produce corrosion to the adhesive materials and do not produce pollution to the surrounding environment. | |
| Typical Applications Include | This product is mainly used in the CRT screen, insulation bonding and sealing for high voltage parts. Like DY deflection coil;fixed and adhesive for PCB sensitive components, capacitors, transistors and so on. | |
| Product Display |
| Hot Sale |
| Product Advantage |
|
|
|
|
Compared with traditional materials, the phase change thermal interface materials can cover and fill the gap and hollow between the contact interfaces when being liquid. |
Company Information
| Company Overview |
| Certificate |
| Contact |
| We can make many specifications according to your request! For more information. Please contact us. | ||||||||||
|
FAQ
| FAQ |
1. What are your main products? We supply thermally conductive pad, thermally silicone RTV, thermally conductive silicone pug, thermally double component silicone, thermally conductive materials, phase change thermal interface materials, thermally conductive insulators and thermal grease. Samples of instant adhesive super glue are available, but the freights need to be paid by the buyers. 2. What about the product quality and which certificate do you have? We have UL certificate and RoHS certificate. 3. How long does it take to deliver after order? For small quantity, we arrange delivery within one week normally while for big quantity, we will arrange delivery as soon as possible according to actual situation and customer's requirements. 4. What about your after-sale service? We fully guarantee our product quality and will provide free technical guidance on operations. |
