Absorbent glass mat (AGM) technology ensures efficient gas recombination up to 99% and freedom from electrolyte maintenance.During the expected float service life of Prostar batteries,no need to check the specific gravity of the electrolyte or add water.
♦ Good Discharging Ability
Tight assembly technology ensures an excellent high-rate discharge performance.
♦ Long Service Life
A unique corrosion-resistant grid alloy ensures Prostar batteries have long service life.
♦ Low Self Discharge
Using high purity raw materials ensures Prostar batteries have less self-discharge.
Specification :
Nominal Voltage
12V
Nominal Capacity (20hour rate)
120Ah
Capacity
25oC
(77°F)
10hour rate (5.55A)
115Ah
5 hour rate (18.3A)
110Ah
1 hour rate (66.5A)
66.5Ah
Internal Resistance
Full Charged Battery 25oC
≤5.0mΩ
Capacity affected by Temperature
(20 hour )
40oC
(104°F)
102%
25oC
(77°F)
100%
0oC
(32°F)
85%
-15oC
(5°F)
65%
Self-Discharge
25oC
(77°F) Capacity
after 3 month storage
90%
after 6 month storage
80%
after 12 month storage
62%
Charge (Constant Voltage) 25oC
(77°F)
Float
Initial Charging Current Less than25.0A
Voltage 13.6-13.8V
Cycle
Initial Charging Current Less than25.0A
Voltage 14.4-14.9V
BatteryDimensions
Length
405mm
Width
172mm
Height
208mm
Total Height
220mm
BoxDimensions
Length
419mm
Width
191mm
Height
299mm
Quantity Per Box
1 PC per box
Net weight Per Cell
33.0kg±400g
Net weight Per Box
33.0kg
Gross Weight
33.5kg
Related Products
Packaging & Shipping
1 piece a carton
Certifications
Our Services
Our battery can used in solar/ups/wind/telecom system and so on. We will give you best service and price.
Company Information
JL is a leading manufacturer and exporter of Battery and Battery Cabinet. Our advanced and professional technology, complete production lines, experienced staff and strict corporate system ensure our products quality. We pride ourselves on quality products, service and pricing, and believe that the three aspects are equally important to ensure the long-term success of overseas purchasing program.
An excellent team which is experienced with market and has strong technical capability to customize cost effective.
OEM/ODM services backed by 16 years' R&D experience.
Factory
FAQ
(1). What’s kinds of battery will you provide? We have three type battery: AGM, Deep cycle and Gel.There are many different model battery here, we can supply 2v 100ah-3000ah battery, 4v 0.25ah-4v 4.5ah battery, 6v 1.3ah-6v 12ah battery, 12v 0.8ah-12v 250ah battery. (2). Your battery can meet CE RoHS requirements? Our battery are with the certificate of CE/RoHS. (3). Can we change the color based on the original? Yes, the color can be customer-made according to your requirement. (4). Can you print my picture or logo on the battery cover? Yes, OEM is available,we can print your picture or logo on the battery case, and you can offer your logo. (5). What kind of guarantee you give? Our battery products can be used for more than 3 years. For AGM battery our warranty time is 1year and GEl battery warranty time is 3years.If it has quality problem during the warranty time we will change new battery for you.
