6.35mm jack usb to guitar audio cable
- Category: >>>
- Supplier: Dongguan Weftai Electronics Co. Ltd.
Share on (60280789806):
Product Overview
Description
6.35mm jack usb to guitar audio cable
6.3mm male to male audio cable
1. 1/4" stereo plug
2. Braid shielding
3. Pure copper wire
Specifications:
Ideal for extending an existing 6.35mm stereo audio cable such as earphones or other audio devices. Nickel contacts and strain relief ends ensure for a tight secure connection.
- Stereo Connections
- Nickel Plated
- Connector A:6.35mm stereo male
- Connector B:6.35mm stereo male
Conductor Material: Copper
Connector Color: Slivery or Gold
Technology process:Cutting ,Crimping ,Welding ,Assembly and Testing
All kinds of Wire harness areRoHs Compliance
Description:
- 6.35mm Stereo Extension cable |
- Connectors:6.35mm stereo plug male to male |
- Fully molding connectors provide excellent strain relief. |
- High-quality cable with braid shielding . |
- Nickle/Gold-plated sterei connectors give you solid corrosion-free contact. |
- Easy installation and convenient to carry |
- Improves digital signal delivery as compared to standard stereo type audio cables. |
- True digital signal maintained by high quality materials and connectors. |
- 99.9% pure copper. |
- High-density double shielding for maximum rejection of EMI and RFI. |
Electrical :
| 1.100% open & short test; |
| 2.Hi-Pot: DC 300V 10ms; |
| 3.Insulation Resistance: 10M OHM /300V Min; |
| 4.Contact Resistance: 0.01 OHM Max; |
| 5.Shield upon 95% braid; |
| 6.Working Temperature: -25 °c~ +85°c |
Mechanical:
| Over mold: | PVC 80Pa ,UL94V-0 Black; |
| Pre mold: | PE Low Density; |
| Contact: | Copper Alloy; |
| Insertion Force: | 35 N Max; |
| Withdraw Force: | 10 N Min. |
