KSFQ G Series High Speed Jumbo Roll Paper Adhesive Label Sticker Automatic Slitter Rewinder Machine

MAX unwind diameter          φ1200mm

MAX REWIND  diameter      φ600mm

Slitting width                         50mm-1300mm

Rewind paper core               3″

Unwind paper core                3″ (6 inch optional)

Max machine speed            500m/min

Drawing motor                     6.5Kw

Rewind motor                      4.5Kw(2 sets)

Unwind motor                      5.5Kw(2 sets)

Whole machine power         33kW

Machine size                       4100X4700x2150mm

Machine weight                   about 4200KG

Machine color                      Black white(or custom’s choice)

If you are looking for a reliable supplier and a long term good

relationship partner  in China? Please fill the message below and click “Send” now.Or you can talk with our sales team online

now.
