hot air banner welding machine

Product Overview

Description

walk welder for tent or banner tarpaulin

(ChunLei Machine)

The two model machine is new tape welding machine , those machine can be used for welding and joining coated fabric , PVC fabric, PE canvas, tarpaulin , outdoor banner, textile-ne, plastic pieces, inkjet cloth, light box cloth and so on

Technical data

Model	Model 4000T
Voltage	220V/230V
Max Power	4000W
Frequency	50/60HZ
Temperature	0-650 degree
Speed	0-12m/min
Welding width	20mm/30mm/40mm/50mm
Gross weight	40kg

Operation steps

1.Check the welding nozzle basic setting , and connect the tool to the mains . The mains voltage must correspond with the voltage stated on the cool

2.Perform a test welding according to the welding instructions of the material , check the test welding . Then adapt the welding temperature as required .

3.Turn hot air blower using positioning lever up to the stop , the outside edge of drive/pressure roller must lone up with the overlap edge of the material to be welded

4.Set temperature and welding speed according to the required value

5.After completing welding work , press the button , so that the hot air blower cools down . Then turn off the air blower switch

Maintenance

1. For safe and effient working , always keep the unit and its ventilation slots clean

2. Clean welding nozzle with wire brush

3. Check mains connection and plug for electrical and mechanical damage

Regarding our machine , if you need more information or have any other questions , please free to contact us , we will do our best for you .



And our company have other machine , such as automatic eyelet machine , hand eyelet machine , hot laminator , cold laminator machine , if you interesting our machine , please tell us , we will send details information to you
