China wholesale price thermal cooling adhesive for pcb
- Category: >>>
- Supplier: Dongguan Sheen Electronic Technology Co. Ltd.
Share on (60292509580):
Product Overview
Description
Thermally Conductive Silicone Potting Waterproof For Power Supply And Power Module
Product Description
| Product Information |
| Product Name | Thermally Conductive Silicone Potting Waterproof For Power Supply And Power Module | ||
| Technical indices | US-5201(0) | ||
| Before curing | Exterior | (White, gray) liquid | |
| Viscosity(cps,25 °C) | 2000~3000 | ||
| Apply proportion(%) | 1:1 | ||
| Viscosity after mixing(cps,25°C) | 2000~3000 | ||
| Operation curing time(hr, 25°C) | 40~60 | ||
| Primary curing time( hr, 25°C) | 4 | ||
| Complete curing time( hr,25°C) | 24 | ||
| After curing | Hardness(shore A, 24hr) | ||
| Line shrinkage(%) | 0.3 | ||
| Use temperature range(°C) | -60~200 | ||
| Volume resistivity | 1.0 X 1015 | ||
| Dielectric strength (kv/mm) | ≥20 | ||
| Dielectric constant(1.2 Mhz) | 2.9 | ||
| Thermal conductivity(W/mk) | 0.8 | ||
| Thermal strength(MPa) | >1.00 | ||
| Shear strength(Mpa) | 1.00 | ||
| Introduction | The Thermal Double Component Silicone (Polyurethane)have the properties of thermal shock resistance,excellent electric properties,and low water absorption.They have deep hardening performance,and high bond strength to coherer,alloy,ceramic,glass or plastic surfaces. | ||
| Features and Benefits | -0.8 W/mK thermal conductivity | ||
| Typical Applications Include | -LED lighting and LED screen -Heat Pipe assemblies | ||
| Product Display |
| Hot Sale |
| Product Advantage |
|
|
|
|
Compared with traditional materials, the phase change thermal interface materials can cover and fill the gap and hollow between the contact interfaces when being liquid. |
Company Information
| Company Overview |
| Certificate |
FAQ
| FAQ |
1. What are your main products? We supply thermally conductive pad, thermally silicone RTV, thermally conductive silicone pug, thermally double component silicone, thermally conductive materials, phase change thermal interface materials, thermally conductive insulators and thermal grease. Samples of thermal silicne rubber are available, but the freights need to be paid by the buyers. 2. What about the product quality and which certificate do you have? We have UL certificate and RoHS,ISO9000,ISO14000,ISO16949 certificate. 3. How long does it take to deliver after order? For small quantity, we arrange delivery within one week normally while for big quantity, we will arrange delivery as soon as possible according to actual situation and customer's requirements. 4. What about your after-sale service? We fully guarantee our product quality and will provide free technical guidance on operations. |
