High Quality Electrically Conductive Silicone Adhesive For Power Supply And Power Module
- Category: >>>
- Supplier: Dongguan Sheen Electronic Technology Co. Ltd.
Share on (60293469438):
Product Overview
Description
High Quality Electrically Conductive Silicone Adhesive For Power Supply And Power Module
Product Description
The Thermal Double Component Silicone (Polyurethane)have the properties of thermal shock resistance,excellent electric properties,and low water absorption.They have deep hardening performance,and high bond strength to coherer,alloy,ceramic,glass or plastic surfaces.
Product Name | High Quality Electrically Conductive Silicone Adhesive For Power Supply And Power Module | |||
Technical indices | US-5201(P) | |||
Before curing | Exterior | white(A)/ gray(B) liquid | ||
Viscosity(cps,25 °C) of component A | 5500~7000 | |||
Viscosity(cps,25 °C) of component B | 2000~3000 | |||
Operating performance | Mix ratio( weight ratio) | A:B=1:1 | ||
Viscosity after mixing | 4000~5000 | |||
Operation time(min,25°C) | 30 | |||
Tack free time (min,25°C) | 60 | |||
Curing time (min,25°C) | 120 | |||
After curing | Hardness(shore A 24hr) | 65 ± 5 | ||
Thermal conductivity(W/mk) | ≥0.75 | |||
Dielectric strength (kv/mm) | ≥27 | |||
Dielectric constant(1.2 Mhz) | 3.0~3.3 | |||
Volume resistivity(Ω, cm) | ≥1.0 X 1016 | |||
Coefficient of linear expansion[m/m.k)] | ≤2.2 X 10-4 | |||
Flame resistance | 94-V0 | |||
Waterproofing grade | ≥IP67 | |||
Features and Benefits | - ≥0.75 W/mK thermal conductivity - High bond strength to coherer, alloy, ceramic,glass or plastic surfaces -Double component, excellent deep hardening performance - Silicone elastomer after hardening -Withstand cool or heat variation long term - Electrically isolating -ROHS compliant | |||
Packaging customization
1kg,5kg,10kg and more
Performance R&D customization
Develop products according to customers' special requirements.
Reliability Test
1000 hours cold and hot shock test
1000 hours high temperature and humidity test
1000 hours vertical drop test & cracking test
Our products have passed 1000 hours cold and hot shock test,1000 hours high temperature and humidity test,1000 hours vertical drop test & cracking test, Committed to providing more reliable heat conduction solutions for automobile, communication, security and other industries.
Sertifications
ISO9001:2015
ISO14001:2015
IATF16949:2016
UL
REACH
ROHS
Details Images
Applications
-LED lighting and LED screen
-Heat Pipe assemblies
-Power supply and power module
-Telecommunication Hardware
-Heat Pipe assemblies
-Power supply and power module
-Telecommunication Hardware
Company Introduction
Dongguan Shengen electronic / Shengyuan New Material Co., Ltd. was founded in 2008. It is a manufacturer specializing in R & D and customization of high reliability thermal conductive materials. We are committed to providing more reliable heat conduction solutions for automobile, communication, security and other industries. The company has a professional R & D team and complete testing equipment. The company's main products are SF thermal conductive silicone sheet, SE thermal conductive gel, SP thermal conductive phase material, AF silicon free thermal pad and SG thermal conductive paste. At present, it has become the main supplier of many well-known manufacturers at home and abroad. The company has obtained iatf16949:2016, iso14001:2015, iso9001:2015 system certification and the title of national high-tech enterprise.
Contact Us
Tel | +86-769-22479425 | Address | 6th Floor, Building M, Jinxiongda Science and Technology Park, Datanglang Villiage, Dalingshan Town, Dongguan City, Guangdong Province, China |
Fax | +86-769-82784017 | ||
Web | //sheen.en.alibaba.com/ //www.usheenthermal.com/ | E-Mail Address | tina@u-sheen.com |
FAQ
1. What are your main products?
We supply thermally conductive pad, thermally silicone RTV, thermally conductive silicone pug, thermally double component
silicone, thermally conductive materials, phase change thermal interface materials, thermally conductive insulators and thermal
grease. Samples of silicone thermally conductive sheet are available, but the freights need to be paid by the buyers.
2. What about the product quality and which certificate do you have?
We have UL certificate,IATF16949,ISO9001,ISO14001 and ROHS certificate.
3. How long does it take to deliver after order?
For small quantity, we arrange delivery within one week normally while for big quantity, we will arrange delivery as soon as
possible according to actual situation and customer's requirements.
4. What about your after-sale service?
We fully guarantee our product quality and will provide free technical guidance on operations.
We supply thermally conductive pad, thermally silicone RTV, thermally conductive silicone pug, thermally double component
silicone, thermally conductive materials, phase change thermal interface materials, thermally conductive insulators and thermal
grease. Samples of silicone thermally conductive sheet are available, but the freights need to be paid by the buyers.
2. What about the product quality and which certificate do you have?
We have UL certificate,IATF16949,ISO9001,ISO14001 and ROHS certificate.
3. How long does it take to deliver after order?
For small quantity, we arrange delivery within one week normally while for big quantity, we will arrange delivery as soon as
possible according to actual situation and customer's requirements.
4. What about your after-sale service?
We fully guarantee our product quality and will provide free technical guidance on operations.
