E71T 1 welding wire

Product Overview

Description













Hebei Yichen New-Type Welding Materials Co., Ltd of Yichen Group specialize in producing flux cored wire, our R&D center works closely with the professional experts and professors from different universitis and national research institutes. Our manufacture facility owns the advanced production equipment, up -to-dated inspection/measurement instrument and the perfect evaluation and quality control systems, we have ISO 9001:2000 certificate.We have 18 production lines with the capacity of 50,000tons per year. Our E71T-1 FCW performs very low spattering, high effective vertical welding, very stable arc and fast welding rate. The diffusible hydrogen content in the deposited metal reaches 3.5ml/100g, which significant avoid the cold cracking and porosity. We are the only FCW supplier in China has 3YH5 certification. We are also the biggest and best quality supplier in China for E71T-GS and E71T-11 self-shielding FCW products.main goods have been certificated by CCS,ABS,DNV,LR,GL,BV,NK,KR,RINA,RS.









Specification Conformance

AWS A5.36 E71T1-C1A0-CS1 GB/T10045-2018   T492T1-1C1A



Description

AWS A5.20E71T-1 is a kind of TI type flux cored wire for CO2 welding ,it has high cladding efficiency, good welding technical performance in all-position welding, apply for low carbon steel and 500MPA grade strength steel welding, such as ships, pressure vessels, mechanical equipments and bridges.



Chemical Composition of Deposited Metal (%)

Chemical Composition of deposited Metal(%)
C	Mn	Si	S	P	others
0.07	1.26	0.36	0.012	0.010	/



Mechanical Properties of Deposited Metal

Mechanical Properties of Deposited Metal
σb (MPa)tensile strength	σs (MPa) yield strength	σ5(%)elongation
570	490	28



AVAILABLE DIAMETER

0.8MM/0.9MM/1.0MM/1.2MM/1.4MM/1.6MM



PACKAGE

 0.45kgs/spool, 0.9kgs/spool, 1kgs/spool: 40spools / box, 32boxes/ pallet

5kgs/spool : 5kgs/carton, 200cartons/pallet

15kgs/spool :72cartons/pallet, 22pallets/20'container

One spool is vacuum packed by aluminum film and then one carton outside



Shielding Gas

100% CO₂



Raw Material:



Production:



Packing:



Ten Certification:



Uses:



Shipping:
