Hot Heat Transfer 0.13mm Brown PTFE Fiberglass Adhesive Tefloning Tape
US $54000-$180000
Product Overview
Description
Products Information
Everflon Fluoropolymer PTFE
EverflonoTM PTFE Suspension Powder M series is a white powder with a small particle size. The small particle size of EverflonTM PTFE M40&90 helps to minimize voids, even at relatively low molding pressures. Its most unique feature is the irregular, fibrous character of the particles. The fibrous particles promote good capture and uniform distribution of inorganic fillers when they are added to modify the mechanical properties of moldings. It offers an excellent combination of properties that are characteristic of EverflonTM fluoroplastic resins.
EverflonTM PTFE Suspension Powder is preferred for moldings requiring optimum mechanical and electrical properties. Its low bulk density limits the size of moldings from a given mold or press opening. It is often preferred for making filled compounds,especially with metal powders that are difficult to mix because of density differences.
The Porperties of Everflon Fluoropolymers
Property | Unit | M40 | M120 |
Average Partical Size | um | 40-90 | 120-180 |
Apparent Density | g/L | 300 | 450 |
Melting Point | °C | 325 | 325 |
Tensile Strength | MPa | >30 | >30 |
Elongation | % | >330 | >330 |
Specific Gravity | g/cm3 | 2.16 | 2.16 |
Water Content | % | <0.04 | <0.04 |
Application
Pad.
Rod.
Sheet
Ring.
Tube
Lining
Packing & Delivery
Storage&Handing
EverflonTM PTFE Suspension Powders' preforming is easiest when the resin is uniformly between 21–27 °C (70–80 °F).
As temperatures decline below this range, the resin will be increasingly difficult to mold without cracks and problems with condensed moisture.
Higher temperatures inhibit flow and promote lumping.
Storage conditions should be set accordingly. Cleanliness is a critical requirement for successful use of EverflonTM PTFE Suspension Powder. The white resin and high sintering temperatures cause even small foreign particles to become visible in finished moldings. Keep resin drums closed and clean. Good housekeeping and careful handling are essential.
Package&Caution
Everflon PTFE Suspension Powder is are packaged in 25kg.(55.1lb ),PE bag, Hard paper drums.
Before processing, please read the Materials Safety Data Sheetcarefully. You could read them from www.everflon.com, or contact us +86-27-84888055 or our local service center, you also should could scan the QR code which on the package to download by your Smartphone
Everflon PTFE
Everflon's PTFE
Polytetrafluoroethylene (PTFE) is a synthetic fluoropolymer of tetrafluoroethylene.
Being hydrophobic, non-wetting, high density and resistant to high temperatures, PTFE is an incredibly versatile material with a wide variety of applications, though it's perhaps best-known for its non-stick properties.
ADVANTAGES OF USING Everflon PTFE Virgin Resins
* Excellent chemical resistance
* Wide range of service temperature
* Excellent dielectric properties
* Non stick, low friction
* No embrittlement or ageing
* Wide range of service temperature
* Excellent dielectric properties
* Non stick, low friction
* No embrittlement or ageing
* Smooth surface finish can be achieved
* Non wetting
* Non wetting
* Outstanding corrosion protection
* Electrical insulation
* High thermal stability and flame resistance
* Resistance to weathering
* Food grade compliancy
AN EXCELLENT ELECTRICAL INSULATOR
It is used frequently as an insulator for wiring and cable, particularly in computer applications, since it is an excellent electric insulator and has a high melting point.
LOW FRICTION
It's low friction also makes it a popular material in mechanical engineering applications. It is regularly used for slide bearings, slide plates, gears and other working parts where sliding action takes place.
RESISTANT TO WEAR
Due to its non-reactivity as well as its tolerance for high temperatures, PTFE is also often used in industrial pipes and hose assemblies in which chemicals and acids are used.
TOLERANT OF HIGH TEMPERATURES
Due to its non-reactivity as well as its tolerance for high temperatures, PTFE is also often used in industrial pipes and hose assemblies in which chemicals and acids are used.
HEALTH APPROVED & FOOD SAFE
This makes it an excellent choice for applications in food manufacturing and packaging, particularly since the material is food grade compliant and resistant to staining.
CHEMICALLY RESISTANT & INERT
Combined with its high temperature resistance PTFE is extremely chemically resistant and chemically inert making it an ideal material for sealing components in chemically aggressive applications.
Visit US
About Everflon Fluoropolymers
Everflon® Fluoropolymer specializes in the production, development, and sales of high-performance fluoropolymer materials. It provides the most basic fluoropolymer raw materials for C&F Group's fluorochemicals. After years of research and development and production, it is currently PTFE, FEP,PFA,ETFE and PVDF materials, and can provide a variety of physical properties of dispersions, granules and powder to meet the needs of various processing applications such as spraying, extrusion, molding, injection molding.
Relying on the Group's Quality Assurance Department and Application Laboratory, Everflon® provides the highest quality and stable fluoroplastic raw materials to meet the high quality requirements of middle and high-end customers and reduce the quality of raw materials caused by production and processing. Problems such as rising costs and inefficiency have established extensive and stable cooperative relations with main-stream manufacturers at home and abroad.
