CK6140T tornos cnc Metal Lathe CNC with Cheap Price

Specifications of CNC Lathe CK6140

Items

Unit

CK6140

Capacity

Max.swing over bed

mm

400

Max.swing over carriage

mm

218

Max turning length

mm

750

Bed width

mm

360

Travel

X axis

mm

210

Z axis

mm

680

Spindle

Spindle speed range

mm

40-1800(2steps)

spindle nose

mm

C6

spindle taper

mm

MT6#

Spindle bore diameter

mm

52

Turret

Tool number

No.

4

Tool shank size

mm

25×25

Change tool times

sec

2.0

Feeds

X -axis rapid traverse

mm/min

4000

Z -axis rapid traverse

mm/min

6000

Cutting feed(Xand Z axis)

mm/r

0.005-100

Tailstock

Taper of tailstock sleeve

MT

5#

Diameter of tail stock sleeve

mm

75

Travel of tail stock sleeve

mm

150

Motor

Main motor power

kw

5.5

X and Z axis torque

N.M

4&6

 Overall dimension(L*W*H)and Weight of  CNC Lathe CK6140

Center Distance

750mm

2150*1300*1700mm/1600kg

CNC Lathe CK6140 Accessories

Standard Accessories

Optional Accessories

GSK980TB2 controller

GSK928TD-L/ GSK980TDc controller

Φ250mmManual 3 jaws chuck

Φ250mm Hydraulic/Pneumatic /Collect chuck

4 position tool turret

6 position tool turret/Hydraulic turret

Manual Tailstock

Hydraulic/Pneumatic Tailstock

X&Z axis AC servo motor

X&Z axis stepping motor

Pump & working lamp

Hydraulic station

Automatic lubricant pump

Automatic bar feeder
