low carbon steel wire hastelloy c276 tig welding wire

Product Overview

Description





hastelloy c276 tig welding wire

c276,c22,c4,b2,b3
wires,strip,plate,tube,bar,fittings
SGS,BV inspection
small order acceptable



                        low carbon steel wire hastelloy c276 tig welding wire



Hastelloy C-276 specification



UNS	Trademark	W.Nr
N10276	HastelloyC276	2.4819



Hastelloy C-276 Chemical composition



Alloy	%	Ni	Cr	Mo	Fe	W	Co	C	Mn	Si	V	P	S
C	Min.	balance	14.5	15	4	3
	Max.		16.5	17	7	4.5	2.5	0.08	1	1	0.35	0.04	0.03
C276	Min.	balance	14.5	15	4	3
	Max.		16.5	17	7	4.5	2.5	0.01	1	0.08	0.35	0.04	0.03



Hastelloy C-276 Physical properties



Density	8.9 g/cm³
Melting point	1325-1370 °C



Hastelloy C-276 Alloy minimum mechanical properties in the room temperature



Alloy status	Tensile strength  Rm N/mm²	Yield strength RP0.2 N/mm²	Elongation  A5 %
Solution treatment	690	283	40



Hastelloy c276 Features

• Excellent corrosion resistance in reducing environments
• Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
• High nickel and molybdenum contents providing good corrosion resistance in reducing environments
• Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected zones of welded joints
• Resistance to localized corrosion such as pitting and stress-corrosion cracking
• One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide

Hastelloy c276 Applications

• Pollution control stack liners, ducts, dampers, scrubbers, stack-gas reheaters, fans and fan housings
• Flue gas desulfurization systems
• Chemical processing components like heat exchangers, reaction vessels, evaporators, and transfer piping
• Sour gas wells
• Pulp and paper production
• Waste treatment
• Pharmaceutical and food processing equipment

Hastelloy C22 Forms

• Sheet
• Plate
• Pipe & Tube (welded and seamless)
• Wire
• Fittings, forgings, flange
• bar















Packaging : standard seaworthy package or as buyer's requirement

Shipping : by sea or airplane

Delivery time : 5-20 days (depends on the quantity of the order)





We have got the certificate as below: ISO 9001,SGS,TUV,BV,ROHS etc.

We also have the APPROVAL OF MANUFACTURING PROCESS,EXPORT INSPECTION EXEMPTION CERTIFICATE,MATERIAL TESTING CERTIFICATE etc.





The reason why you choose us

1.  We can offer full range of stainless steel products.You are welcome to visit our product catalogue.
2.  We have complete and professional product testing system, so we can guarantee the quality and thickness of the products.
3.  Reliable certificate.(ISO,BV,SGS,etc)
4. Good and quick service. We guarantee reply your message within 24 hours.
5.  Personalized services.We can produce according to your requirements.



Q1.Do you attend exhibition every year?



A .Yes



Q2.Is there any discount of the nickel wire?



A.  Yes. Bigger quantity will get lower discount.



Q3.Information needed if I want a quotation?



A  Name, Standard, Material Grade(Chemical Composition), Size Quantity, Weight.



Q4. Can we visit your company/factory before place the order?



A. Yes. Welcome anytime



Q5: How does your factory do regarding quality control?



A. Quality is priority. We always attach great importance to quality controlling from beginning to end.



How to contact us?



Send your inquiry details in the below for free sample, click "send" now.
