CF47II A3 size single color offset press machine

Product Overview

Description

CF47II offset printing machine



Introductions:



 1) Perfectiy designed,these printing machines are a new type of functional,economical and practical offset presses for planographic printing and code printing.



2) on the basis of the II-generation offset presses, in addition to all the functions of single-color coding offset presses, they also have the advantages of beautiful color and solid printing with large ink amount as second-generation offset presses. They are really multi-functional, widely applicable, and high quality printing machines with high printing quality.



1.  Applicable scope:This machine is suitable for schools,hospital,Medium and small companies etc.



2. Products: business forms,exam papers, prescription sheet,NCR(carbonless)bills,notebooks,exercise book etc.

3.consumable items:paper from 17-250gsm,normal 1.95mm blanket,common aluminium plate.



4.Main fuction: Printing,Numbering,perforating can be finished at a time.



5.Main parts:1)much thicker and heavier cylinder Pressure NO PROBLEM! 2.)cast iron wall and metal case hardening and galvanized .3) gears and bearings hardened.4)electric apparatus.Panasonic PLC,Taian Converter.Mikom sensor. Automatic controll system.



6.Feed system/Inking system/numbering system/delivery system:Auto-feeding system,double sheet sensor. Auto damping and inking device/numerbing perforating 2 in 1./delivery auto up and down system.



7.Operation: We send the manual and videos. If possible we can send the techician.



8.Aftersale service: The machine have a year warranty. We send as many spare parts as possible.



Specifications:



Maximum printing area	454 x 345mm
Maximum paper size	470 x 365mm
Minimum paper size	90 x 140mm
Paper type	17-250g/m
Number of ink rollers	Main machine system :10pieces (3 form rollers) NP system 6 pieces 2 form rollers
Number of dampening rollers	4 pieces (1 form rollers)
Minimum space between codes	Vertical code vertical 71mm horizontal 48mm	Gripper edge 25mm
	Horizontal code vertical 47mm horizontal 60mm	Gripper edge 25mm
Registration mechanism	Roller type side lays
Printing speed	2000-8000 sheets/hour
Motor power	Main motor: 0.75KW/380V	Air pump moto:0.55KW/380V
Machine size	2089L×1030W×1189Hmm
Weight	700KG





Parts:



 Product sample:



Exhibition :
