50L/min China Airborne Particle Counter Clean Room Pharma

Product Overview

Description



Y09-550 /Y09-350/Y09-5100

50LPM-Airborne Particle Counter



Y09-550 /Y09-350 airborne particle counter (hereinafter referred to as the instrument) is used to measure the size and quantity of dust particles per unit volume of air, and can directly verify ISO Class 5-8 (EU GMP Grade A-D) clean environments.

The instrument uses a laser diode light source, with touch screen (LCD) display, having such advantages like reasonable structure, high accuracy large flow rate, short sampling time, simple and convenient operation. The testing data can be directly stored in the U disk without computer acquisition, also it is micro computer controlled, can print sampling results by miniature built-in thermal printer. The instrument is widely used in electronic, optical, chemical, food, cosmetics, pharmaceuticals, biological products, aviation and aerospace etc.



l  Simultaneously display of up to six particle size

l  20000-record data storage memory

l  Meet the requirements of ISO14644-1:2015









	Y09-550	Y09-350	Y09-5100
Outside Dim	268×192×292(mm3)
Display	LCD
Weight	6 Kg
Max.Consumption	80W
Power Source	AC 220V±10%; DC16.8V (Built-in Lithium Battery)
Size Channels	0.5,1, 3, 5, 10, 25μm	0.3,0.5, 1, 3, 5, 10μm	0.5, 1, 3, 5, 10, 25μm
Calculation	95%UCL calculation,showing particle concentration(particles/cubic meter, particles/cubic feet)
Flow Rate	50L/min( Imported Pump)		100L/min (Imported Pump)
Sample Time	6~999999s(Selectable)
Zero Count	≤10min
Location	1~99
Printer	Built-in Thermal Printer
Alarm	Class
Data Storage	20000 Samples/300Samples of UCL(With PC Software)
Data Output	USB Port
Light Source	Laser Diode(30000 hours mean time between failures)
Maximum Rated Particle Concentration	35000 particles/L
Operating Time	More than 5.5 hours
Environmental	Temperature:10~35℃; Humidity:20%~75%RH; Atmosphere Pressure:86~106Kpa











Suzhou Sujing Automation Instrument Equipment Co., Ltd. (herein after referred to as Sujing Instrument) is boasting the largest market share in the particle measurement field in China, with complete integration of scientific research, development and production.

Sujing Instrument is one subsidiary company of Sujing Group.(Sujing Group has 11 subsidiary companies)

Sujing brand has been granted the honor of "China Famous Brand" since 1983. Sujing Group has been keeping the first place among competitors in the same industry for 35 years in a row.
  The mission of Sujing Instrument is to provide products and services accociated with particle measurement and monitoring, which are application driven.



Sujing instrument is an ISO 9001:2015 Registered Company
