No Noise Cross Filament Tape GF 0305 2206W

Product Overview

Description









---





 Widely Used Fiberglass Reinforced Filament Tape GF-0305-575





Features:



The reinforced fiberglass yarn of Premium Grade Filament Tape GF-0305-575 provides the filament tapes high tensile strength;the PET film backing provides excellent abrasion and moisture resistance. The proper packaging-grade adhesive is specially to provide good initial adhesion & long-term holding power.



---





Typical Physical  Properties (21 Degree, stainless steel)			Note:    Typical data for reference, not for specification purpose.
									Testing method
			Peel adhesion at 180°:			55±5N/inch			D 3330
			Tensile Strength:			600N/inch			D 3759
			Elongation at Break:			3%			D 3759
			Holding Power:			>72h			D 3654
			Total Thickness:			145mu			D 3652









Little knowledge for tape application:



1.The laminated adhesion depends on the contact area therefore a proper pressure & time helps improve the adhesion strength.



2.The substrates should be clean without oil, clean using solvents when necessary.



3.The best laminate temperature is room temperature; it becomes hard when temperature approach 0℃ as the adhesive film becomes firm.
