WSME315D Inverter AC/DC pulse TIG/MMA dual voltage 3Phases 220/380V welding equipment
- Category: >>>
- Supplier: Shanghai Rongyi Welding Corporation
Share on (60313428462):
Product Overview
Description
Features of WSME315D Inverter AC/DC pulse TIG/MMA dual voltage 3Phases 220/380V welding equipment:
1. Reactive power correction, inverter, soft switch technology, square wave power supply;
2. Compact structure, stable welding current, steady and intensive arc, foot pedal controller interface for safe operation, reliable and durable, easy for maintenance;
3. Strong capability of oxide film cleaning, fantastic welder performance;
4. Thermostatic protection, over-voltage protection, over-current protection, under-voltage protection;
5. High duty cycle, continuous operation without interruption at large current;
6. DC welder suitable for stainless steel, alloy steel, carbon steel, copper, titanium, etc;
7. AC welder suitable for aluminum and aluminum alloy;
8. Complete accessories: welding torch, welding cable, earth clamp, welding holder.
Parameters of WSME315D Inverter AC/DC pulse TIG/MMA dual voltage 3Phases 220/380V welding equipment :
Model Spec. | WSME315D |
Power supply voltage | 3-ph AC 220/380±10% V / 50~60 Hz |
Power supply capacity | 7.6 kVA |
Rated input current | 20 A |
Duty cycle | 60% |
Output current range | 5-315 A |
Cleaning proportion | -40%~+40% |
PWM range | 10%-99% |
Up-slope time | 0.1-15 s |
Down-slope time | 0.1-15 s |
Efficiency | 77% |
Cosφ (η) | 0.95 |
Weight | 50.8 kg |
Dimensions (mm) | 650*325*585 |
* BUY WITH CONFIDENCE.
* QUALITY MACHINES MANUFACTURED BY RONGYI.
* FULL SERVICE AND PARTS BACK UP.
* 12 MONTHS WARRANTY.
The data in the above table is only for reference. Please subject to the nameplate on the device.
