China factory manufacture hydroforming AM350 bellows pipe fittings
- Category: >>>
- Supplier: Jiangsu Aidi Electromechanical Equipment Industry Co. Ltd.
Share on (60313812690):
Product Overview
Description
Company Introduction --- Exhaust bellows pipe Manufacturer We Jiangsu Aidi Electromechanical Equipment Industry Co., Ltd, which specialized in manufacturing
stainless steel bellows, bellows components, bellows compensator and bellows equipment for many years,
We have complete product specifications, strong production capacity, prompt delivery and strong design,
production capacity of non-standard products.
Exhaust bellows pipe
| Bellows Material | stainless steel 304,304L,316L,316Ti,321 and etc. Inconel 625, |
| Bellows Inner Diameter | DN9.8--DN400 |
| Bellows Outer Diameter | DN15--DN450 |
| Bellows Wall Thickness | 0.1mm-0.8mm |
| Single Layer or Multilayer | 1ply---5plies |
| Working Pressure | 0.1~2.5Mpa |
| Bellows Wave Distance | According Drawing |
| Working Temperature | -196--450°C |
| Original Place | China (mainland) |
| Connection Mode | Threaded connection |
| Length | According your requirements |
| Connecting Size | DN12~DN400 |
| Technology | Hot rolled, Cold drawn,Pickled,Forged, |
| Angle direction compensate | 10-40 degree |
| Consult standard | AISI,ASME,GB/T14525-1999 or GB/T12777-2008 national standard |
| Features | large amount of compensation and long life |
| Certification | ISO9001:2000 |
| Packing & Size | Fristly in the plastic bag,and in the carton or wooden box |
Bellow Data Sheet
| Specification | ID(d) | OD(D) | Wave thickness(t) | Layer Number(n) | Wave distance(q) |
| DN10 | 10 | 16 | 0.12 | 2 | 2.5 |
| DN12 | 12 | 20 | 0.15 | 2-3 | 2.5 |
| DN16 | 16 | 25 | 0.15 | 2-3 | 3 |
| DN18 | 18 | 28 | 0.15 | 2 | 3 |
| DN22 | 22 | 32 | 0.15 | 2-3 | 3.5 |
| DN25 | 25 | 38 | 0.15 | 2-3 | 4 |
| DN28 | 28 | 40 | 0.15 | 2 | 3.5 |
| DN32 | 32 | 45 | 0.16 | 2-3 | 4 |
| DN35 | 35 | 50 | 0.2 | 2-3 | 5 |
| DN40 | 40 | 60 | 0.3 | 2-3 | 5 |
| DN50 | 50 | 70 | 0.3 | 2-3 | 5 |
| DN65 | 65 | 90 | 0.3 | 2-3 | 5.8 |
| DN80 | 80 | 105 | 0.35 | 2 | 7 |
| DN100 | 100 | 130 | 0.35 | 2 | 7.5 |
| DN125 | 125 | 157 | 0.4 | 2 | 11.5 |
| DN150 | 150 | 200 | 0.5 | 2 | 12 |
Notes:
1. The table above is parameters table for multilayer;
2. The table above is part specifications of our bellows, some specifications have a variety of wave distance and wall thickness;
3. Specifications excluded in the table can be customized to design, mold and purchase raw materials according to your requirements.
| Specification | ID(d) | OD(D) | Wave distance(q) | Wall thickness(t) | Specification | ID(d) | OD(D) | Wave distance(q) | Wall thickness(t) | |
| DN10 | 10 | 15 | 1.8 | 0.11 | DN52 | 52 | 70 | 5 | 0.2 | |
| DN12 | 12 | 20 | 2 | 0.12 | DN55 | 55 | 80 | 5.5 | 0.2 | |
| DN14 | 14 | 22 | 2.2 | 0.12 | DN60 | 60 | 80 | 5.5 | 0.18 | |
| DN15 | 15 | 23 | 2.2 | 0.15 | DN65 | 65 | 89 | 5.7 | 0.2 | |
| DN16 | 16 | 25 | 2.3 | 0.12 | DN72 | 72 | 100 | 5.9 | 0.3 | |
| DN17 | 17 | 26 | 2 | 0.12 | DN75 | 75 | 100 | 6 | 0.2 | |
| DN18 | 18 | 28 | 2.6 | 0.12 | DN80 | 80 | 105 | 7 | 0.2 | |
| DN19 | 19 | 30 | 2.3 | 0.12 | DN82 | 82 | 110 | 4 | 0.2 | |
| DN21 | 21 | 32 | 2.5 | 0.12 | DN85 | 85 | 110 | 12 | 0.3 | |
| DN22 | 22 | 32 | 3 | 0.13 | DN90 | 90 | 115 | 6.5 | 0.3 | |
| DN24 | 24 | 34 | 3 | 0.13 | DN95 | 95 | 125 | 9 | 0.3 | |
| DN25 | 25 | 38 | 3 | 0.12 | DN100 | 100 | 130 | 7.5 | 0.25 | |
| DN28 | 28 | 40 | 3.2 | 0.12 | DN120 | 120 | 157 | 10 | 0.3 | |
| DN30 | 30 | 44 | 4.2 | 0.15 | DN125 | 125 | 165 | 12 | 0.3 | |
| DN32 | 32 | 45 | 3.4 | 0.13 | DN130 | 130 | 170 | 8 | 0.25 | |
| DN35 | 35 | 50 | 3.5 | 0.13 | DN135 | 135 | 175 | 11 | 0.3 | |
| DN38 | 38 | 55 | 3.8 | 0.15 | DN150 | 150 | 200 | 12 | 0.25 | |
| DN40 | 40 | 60 | 3.8 | 0.2 | DN165 | 165 | 200 | 10 | 0.3 | |
| DN42 | 42 | 60 | 4.4 | 0.15 | DN200 | 200 | 250 | 12 | 0.3 | |
| DN45 | 45 | 65 | 4.5 | 0.15 | DN220 | 220 | 255 | 8.6 | 0.3 | |
| DN48 | 48 | 65 | 4.5 | 0.18 | DN250 | 250 | 300 | 15 | 0.3 | |
| DN49 | 49 | 65 | 3 | 0.15 | DN280 | 280 | 330 | 18 | 0.3 | |
| DN50 | 50 | 70 | 5 | 0.2 | DN300 | 300 | 350 | 18 | 0.35 |
Notes:
1. The table above is parameters table for single layer;
2. The table above is part specifications of our bellows, some specifications have a variety of wave distance and wall thickness;
3. Specifications excluded in the table can be customized to design, mold and purchase raw materials according to your requirements.
Welding Flange Bellow Inspection Testers
Welding Flange Bellow Application
Foreign Cooperation
Certifications
Contact us
Telephone: 86-25-84981632
Mobile Phone: 17674062103
Fax: 86-25-84981642
Company Name: Jiangsu Aidi Electromechanical Equipment Industry Co., Ltd.
Operational Address: North Gate Of No. 5, Rungu Rd., Guli Industrial Park, Jiangning District, Nanjing, Jiangsu, China (Mainland)
Our motivation comes from your support and feedback.Welcome your feedback on any questions, we will arrange technical person to service for you!
