HW368 Yarn Doubling Winder Machine Manufacturer of Spinning Machine
- Category: >>>
- Supplier: Wuxi Huawen Machinery & Electronics Co. Ltd.
Share on (60314266891):
Product Overview
Description
HW368 Yarn Doubling Winder Machine Manufacturer of Spinning Machine
Product Description
Application:
Mainly applicable to joining cotton, wool, polyester, chemical fiber and blended yarns, double raw material bobbins of different specifications into parallel bobbins for processing on short twisting machine.The fore equipment of two-for-one twister for short fiber, can make two or three yarns into one and wind into parallel bobbin.
Main Features:
1. Adopting one motor control one spindle system, easy to adjust yarn speed and winding;
2. Frequency control and broken twsting device avoiding yarns missed;
3. Electron measure device, which can adjust surface speed and the length of yarn;
4. Adopting center computer control system, which ensure correct data;
5. Adopting advanced prevent overlap system, make finished yarn has a nice shape;
6. Single layer,single side, control box was made by plate.
Main Specifications
Main Specifications
1 | Spindle Gauge | 310mm |
2 | Spindle Number | 96 Spindles (12 spindles/ section) |
3 | Number of Yarns | 2-3 Yarns |
4 | Spindle Speed | 650m/min |
5 | Form of Twist | Cylinder |
6 | Range of Twist | Φ130- Φ190 x L152mm |
7 | Transfer Method | Single spindle transfer |
8 | Avoiding Overlap | Transducer Control |
9 | Motor Power | 90 W/Spindle |
10 | Grooved Drum | Metal material with 2.5 circles constant velocity type |
11 | Auto-stop device for breakage | One set each spindle, electric induction |
12 | Outside Dimension | 15300 x1650 x1520mm (L x W x H) |
Customer Visiting
Customer Visiting:
Packaging & Shipping
Packaging & Shipping:
We mostly use the nude cargo with waterproof plastic bags. We will separate the whole machine into sections after adjustment, and then put each section one by one into the container.
FAQ
FAQ
Are you the manufacturer or the trading company?
We are the experienced manufacturer of textile machines, especially for the two-for-one twisting machines, doubling winder machines, yarn covering machines and etc. We have got the self-support imports and exports right.
What is your advantage compared with other textile manufacturers?
We are expert at making yarn machines over 15 years and we have a professional technical team who can provide special customer requirements, so that we are able to make machines with high quality and reasonable price.
What kind of service can you offer?
Design with your requirements by professional team.
ISO 9001:2008 certificates and letters patent
Engineers go overseas for training.
How to check my order at last?
We warmly welcome you to visit our company in Wuxi, which is close to Shanghai, for checking your machines. If you don’t come here, we can also take photos and videos for your conformation.
Certifications
Certifications:
Company Information
Company Information:
