Product Overview
Description
pure zinc wires metalizing
use in arc and flame spray systems
well bonding coatings
high-temperature corrosion protection
ISO 9001
high purity 99.99% pure zinc wires metalizing
Zinc wire 99.995% , ( Pure Zinc wire , Zinc wire for capacitors )
| Chemical composition | Zn | Cd | Pb | Fe | Cu | Total non-zinc |
Nominal value | ≥99.995 | ≤0.002 | ≤0.003 | ≤0.002 | ≤0.001 | 0.005 |
| Actual value | 99.9957 | 0.0017 | 0.0015 | 0.0008 | 0.0003 | 0.0043 |
| Term | Specification |
| Tensile strength M pa | 115±10 |
| Elongation % | 45±5 |
| melting point | 419 |
| Density g/m3 | 7.14 |
Pure Zinc Wire
- zinc wire with 99.99% purity
- zinc wire with spool
- zinc wire in drum
- zinc wire for metal spray coating
- zinc wire for thermal spray coating
Key benefits:
- Purity Zn > 99,995%, EN 117921 .
- Low Cadmium content: Cd 0,0002 - 0,0005 = only ca. 50% of the highest content allowed according to EN 117921 .
- Remarkable adhesiveness of zinc .
- Clean and smooth surface of the wire (good electric conductivity and high durability of nozzle) .
Specification for spraying zinc wire
Product name | Diameter | Package | Zinc content | Application |
Zinc wire
| Φ1.3mm | 25kg/Barrel package;15-18kg/Axle package;50-200/Diameter | ≥99.9953 | Applicable to ductile pipes, power capacitors, power towel,towel, container, derrick, bridges gate, tunnel framework, metal stents, large steel structure surface thermal spraying zinc corrosion protection industry. |
Φ1.6mm | 25kg/Barrel package;15-18kg/Axle package;50-200/Diameter | ≥99.9953 | ||
Φ2.0mm | 25kg/Barrel package;15-18kg/Axle package;50-200/Diameter | ≥99.9953 | ||
Φ2.3mm | 25kg/Barrel package;15-18kg/Axle package;50-200/Diameter | ≥99.9953 | ||
Φ2.8mm | 25kg/Barrel package;15-18kg/Axle package;50-200/Diameter | ≥99.9953 | ||
Φ3.0mm | 25kg/Barrel package;15-18kg/Axle package;50-200/Diameter | ≥99.9953 | ||
Φ3.175mm | 250kg/Diameter | ≥99.9953 | ||
Φ4.0mm | 200kg/Diameter | ≥99.9953 |
ZnAl2, ZnAl4, ZnAl15 (other alloys on request)
Standard diameters: 0.8mm - 5.0 mm according to DIN EN 14919:2001
Package: 25kg/Bundle 15kg ~20kg/Spool 50kg —250kg/Barrel
Application
Application:
SZNK manufactures zinc and zinc/aluminum alloy wires used for Zinc Thermal Spray, often called Metalized Coatings. Zinc and zinc alloy wire sprayed coatings are integral steps in the manufacture of various electronic, capacitor, automotive, heat exchanger and tube & pipe products. Thermally Sprayed Zinc based alloy wire coatings are also used in the Corrosion protection of bridges, locks & dams, above ground storage tanks, light poles, and other critical infrastructure.
Pure Zinc Wire: 0 VOC Coating. Melting Point: 787°. Bond Strength aim is 500 psi. Max Service Temp is 140°. Coating coverage estimate per pound @ 6 mils thickness is 3.5 sq. foot per pound.
98/2 Zinc/Aluminum Wire: an alloy of 98% zinc and 2% aluminum by weight. Used as a coating sprayed onto steel, the alloy produces a coating with the best anti corrosion characteristics of both metals for optimum corrosion protection along with many uses as a solder wire. Melting Point: 800° Bond Strength: 600 psi. Max. Service Temp est 180°.0 VOC Coating.
96/4 Zinc/Aluminum Wire: an alloy of 96% zinc and 4% aluminum by weight. Used as a coating sprayed
onto steel, the alloy produces a coating with the best anti corrosion characteristics of both metals for optimum corrosion protection along with many uses as a solder wire. Melting Point: 800° Bond Strength: 600 psi. Max. Service Temp est 180°.0 VOC Coating.
85/15 Zinc/Aluminum Wire: an alloy of 85% zinc and 15% aluminum by weight. When sprayed onto steel, the alloy produces a coating with the best anti corrosion characteristics of both metals for optimum corrosion protection. This corrosion resistance alloy is especially effective on steel against sodium chloride (salt), sulfur dioxide and marine environments.Melting Point: 824° Bond Strength: 700 psi. Max Service Temp. 600° f. Coverage per pound @ 6 mils: 4.3 sq. ft./lbs. 0 VOC Coating.
Packaging & Shipping
Transport:
100 tons pure zinc wire was exported to Germany for capacitor factory.
CERTIFICATES
Why choose us
Why choose our SZNK zinc wire ?
- Adopt superior zinc ingot (99.9953% min) as raw materials and execute ministerial standard & national GB/T470-2008 standard,
- Strictly executes Q/82SZL 01-2009 standard for zinc wire quality.
- Look smooth, no greasy dirt, no crack no mar or scar.
- Advanced testing equipment, implement "three inspection" quality control ( raw material inspection, process inspection, finished goods inspection).
- Highly appraised by clients at home and abroad.
- we can also produce special zinc wire, Zn85Al15 wire, Aluminum wire according to user's requirements.
