10A 20A 30A / 0 10mA mini encapsulated current transformer
- Category: >>>
- Supplier: Beijing Yaohua Dechang Electronic Co. Ltd.Beijing Ltd.
Share on (60315042592):
Product Overview
Description
Product Description
Product Description
Through core Precision current transformer
Brand : YHDC Model : TA17
Primary current : 10A/20A/30A AC
secondary current : 0-10mA AC
Linearity : less than 0.2
Diameter : 6.5mm
Mounting type : PCB
Turn ratios : 1/1000 or 1/2000 or 1/3000 ( can be changed as your request)
Table of technical parameters | |||||||||
Model | Transformation ratio | Input current | Output current | Sampling resistance | Non-linearity | Weight | |||
TA17-100 | 1000:1 | 0-10A | 0-10mA | 50Ω | ≤0.2% | 16g | |||
TA17-200 | 2000:1 | 0-20A | 0-10mA | 300Ω | ≤0.2% | 16g | |||
TA17-300 | 3000:1 | 0-30A | 0-10mA | 450Ω | ≤0.2% | 16g | |||
Work frequency | 20Hz-20KHz | Operating temperature | -20°C~+70°C | Dielectric strength | 3.5V AC/1min | ||||
Detailed Images
Detailed Images
Company Information
Q: Do you provide samples? Can the product be customized?
A: Yes.
Q: How long is your delivery time?
A: 5-7 working days .
Q:Are you trading company or manufacturer?
A:We are factory.
Q:How can I place an order?
A: You can contact us by email about your order details, or place order online directly.
