Good Quality High Temperature Resistance Ceramic Fiber Round Braided Rope

Product Overview

Description



Introduction

High temperature ceramic fiber rope, is made from ceramic fiber wool, non-alkali glass filament, high temperature resistant stainless steel alloy wire with special technology. In addition to the above products, we also provide high temperature resistant textile with special specifications and performance for our customers according to their requirement for service temperature and specific service conditions.

ProductCategory

Standard ceramic fiber rope

Reinforced glass silk

Reinforced stainless steel wire

Characteristics

• Excellent high temperature strength


• Good electrical insulation performance


• Excellent corrosion resistant of acid, oil and water vapor


• Low heat Conductivity


• Excellent heat insulation performance

 Technical Index

Main Performance	Reinforced Stainless Steel Wire	Reinforced Continuous Glass Fiber
Highest Service Temperature    (°C)	1050	650
MeltingPoint(°C)	1760	1760
Density(kg/m3)	350-600	350-600
Heat Conductivity(W/m·k, ASTMC201) (average 800°C)	0.17	0.17
Ignition Loss(%)	10-20	10-20
ChemicalComponent
Al2O3	46.6	46.6
Al2O3+SiO2	99.4	99.4
Product Standard Specification
Fiber Cloth	Width: 1000-1500mm, thickness: 2, 2.5, 3, 5, 6mm
Fiber Tape	Width: 10-150mm, thickness: 2, 2.5, 3, 5, 6, 8, 10mm
Fiber Twisted Rope	Diameter: 5, 8, 10, 12, 15, 18, 20, 25, 30, 35, 40mm
Fiber Round Strand Rope	Diameter: 5, 6, 8, 10, 12, 14, 15, 16, 18, 20, 25, 30, 35, 40, 45, 50mm
Fiber Square Rope	5*5, 8*8, 10*10, 12*12, 14*14, 15*15, 16*16, 18*18, 20*20, 25*25, 30*30, 35*35, 40*40, 45*45, 50*50mm

Applications

High temperature ceramic fiber rope: thermal insulation for high temperature pipeline and containers, thermal radiation shield, labor insurance clothing, high-temperature resistant fireproof curtain, protection for cable or fuel pipe, high temperature resistant metal compensator refractory layer and others industrial thermal insulation, fireproof and protection.
