Poultry Farm Used Steel Feed Storage Small Silo

Product Overview

Description

Specifications

Assembled hot galvanized poultry feed bins/feed silos
Provide Turkey Project

As a professional manufacturer of storage equipment, we have developed, designed and manufactured assembly steel silos



Features of Feed silo

The standard ladder and fence is safe and reliable.

The feed bin is fastened strongly and sealed.

Our feed bin made by high quality galvanized steel sheet.

Bin lever indicators at bottom and roof



Advantages

1). Silo standard ladder which has a guard railing and is safe and reliable;

2). Firm connection and good sealing performance;

3). High-quality plates, for more than 10-year service life



FEED BIN LIST





1.8M Diameter Poultry Feed Silo W/60o Hopper



Model Number	Metric Tons	Cubic Meter	Height(M)
18-0060-1	2.9 tons	4.5 m3	3.5 m
18-0060-2	4.4 tons	6.8 m3	4.4 m
18-0060-3	5.8 tons	9.0 m3	5.3 m







  2.75M Diameter Poultry Feed Silo W/60o Hopper



Model Number	Metric Tons	Cubic Meter	Height(M)
27-0060-1	7.8 tons	12.1 m3	4.8 m
27-0060-2	11.2 tons	17.4 m3	5.7 m
27-0060-3	14.6 tons	22.6 m3	6.6 m







 3.05M Diameter Poultry Feed Silo W/60o Hopper



Model Number	Metric Tons	Cubic Meter	Height(M)
30-0060-1	10.0 tons	15.6 m3	5.0 m
30-0060-2	14.0 tons	22.2 m3	5.9 m
30-0060-3	18.6 tons	28.8 m3	6.8 m







 3.6M Diameter Poultry Feed Silo W/60o Hopper



Model Number	Metric Tons	Cubic Meter	Height(M)
36-0060-1	16.0 tons	25.0 m3	6.0 m
36-0060-2	21.6 tons	33.5 m3	6.9 m
36-0060-3	27.0 tons	42.0 m3	7.8 m
