China high pressure welding ball valve DN10

Product Overview

Description

10000 psig stainless steel high quality ball valve



Features of high quality ball valve

1.Blowout proof design with internally loaded stem
2.Handle indicates the flow direction
3.Positive stop with a robust stop pin
4.High flow rate with maximum orifice
5.Various flow control with side and bottom inlet port on 3-way diverter valves
6.Valves are designed to control fluids in full open or full closed position
7.Valves that have not been actuated for a period of time may have a higher initial actuation torque
8.Valves must be in open position during system test not to damage the valve seat

9.Optional pneumatic and electric actuator
10.Standard maximum pressures:
      Stainless steel: 6000 psig (413 bar)
      High pressure up to 10 000 psi (689 bar)
      Temperatures up to 450°F (232°C)
11.Suitable for sour gas service; materials are selected inaccordance with NACE MR0175/ISO 15156
12.Every valve is 100% factory tested with nitrogen

Parameter

Name	10000 psig stainless steel high quality ball valve
Structure	Ball
Material	Stainless steel
Port size	1/8"~32mm
Brand name	JW-LOK
Pressure	High pressure
Certificate	ISO9001:2008TS
Package	Carton, wooden case or upon your request
Origin	Jiangsu, china



  If you need more detailed product information .

we can send you catalog and drawing to your email.
