Manual hand portable multifunctional glass edge grinding and polishing machine,portable glass edge grinder

 Specifications:

 Item name : Manual hand portable multifunctional glass edge grinding and polishing machine,portable glass edge grinder

Voltage:220V
Power:680W
Grinding Speed: 1-3r/min

RPM: 8000r/min

Dimension: 29*15*26cm

Weight: 6.84 kg

 Introduction:

1. The supported plate and main components are made of Aluminum Alloy, which makes

machine high-strength and impact resistance.

2. The machine is driven in high-speed by Single Phase Series Motor and its grinder is

otated in high-velocity by Belt-driven Transmission Shaft, which is of transmission

stabilization and low noise.

3.The operation parts are taken E-grade Insulation Material into application, which

effectively improve safety performance.

4.The machine is mainly designed to grinding the object of curve shape or arc and the

edge of plate. Equipped with diamond wheel, it is able to grind the hard-brittle

materials such as glass, stone and ceramic and so on. Used with different shape wheel,

it can make objects in difference shapes like Pencil Edge, Bevel and Flat-with-arris

Edge etc.

5. It is most popular and adaptable in customer experience by its small size, light in weight,

full function, portability, easy operation.

Safety Instruction:

1) Before use this machine, check if the Electrical Wire and Grounding Cord are in

good condition (it’s not allowed to use if any broken cord and electrical leakage

happens); Check if the motor is in dry condition. It’s better to arrange the

Electrical Leakage Protection Device.

2) Wear Insulated Glove when working.

3) For Grinding Wheel Life-Spam and grinding efficiency, sufficient cool water

pressure is required.

4) Decrease the machine pressure at sharply-reduced operating speed to avoid

overload operation that would damage motor easily.

5) Check Carbon Brush frequently and replace it if in need in time for avoiding

wearing out motor rotor.
