What is the technical data of our solar collector?
Technical Data of heat pipe solar collector
Description
Heat pipe solar collectors
Numbers of tube(pcs)
15
Absorber area approx.(m2)
1.406
Hydraulic Connections
G3/4" male thread
Fluid volume(L)
0.75
Maximum operation pressure(Bar)
6
Test pressure(Bar)
9
Heat transfer fluid
Anti-freeze Fluid (Water-Glycol)
Max.working temp.
250C
hot water(L/Day)
150
35C (Radiation>=800w/m2.day)
Collector efficiency
76.40%
Medium
Pure water
Start-up Temperature of heat pipe
<=30C
warranty
5 years
Whats the principle of our solar collector
1. The heat pipe series solar collector are always connected with existing heating supply device.
2. The selective coating on the inner Cover of the evacuated tubes converts solar energy into heat energy and transfers heat to the heat pipes by aluminium fins.
3. The liquid in the heat pipe changes into vapour which rises to the condenser.
4. The heat then passes through the heat exchanger and the vapour becomes liquid, returning to the base of the heat pipe.
5. The heat conducts to the heat transfer liquid (anti-freezing liquid or water) via a copper pipe.
6. This transference of heat into the liquid creates a continuous circulation as long as the collector is heated by the sun.
Product Photos
Product Features
Whats the application of our solar collector
1. Hotels, resorts, hospitals and hostels 2. Process industry, boiler feed, laundry and canteens 3. Agricultural sector, hatcheries and dairies 4. Process industry, Boiler feed, Laundry and canteens 5. Agricultural sector, hatcheries, and dairies 6. Swimming pool heating 7. In-process heating 8. Health clubs (Steam / Sauna)
