Product Overview
Description
Residential Pitched tile roof solar panel mounting system 10KW
Product Description
1> Product Description
Off-Grid 10000w Solar Power System Technical Data
Item No. | RSM10000-OFF | |
Capacity | 10000VA | |
Daily power consumption | Solar radiation 3-5 hours 30KWH-50KWH | |
System voltage | 216V | |
Solar panel | Type | RSM72-156P-280 |
Pmax | 280W | |
Vmp | 35.99V | |
Imp | 7.78A | |
Inverter | SPEC. | 10KW |
Wave form | Pure sine wave | |
Output voltage | AC110V/220V | |
Output Frequency | 50Hz/60Hz | |
Inverter Efficiency | 90% | |
Controller | Rated voltage | 216V |
Rated current | 50A | |
Control mode | PWM | |
Protection | Reverse polarity, overload, reverse charge,etc. | |
Battery | Battery Type | Sealed Gel |
Voltage | 12V | |
Capacity | 250AH | |
Distribution Box | Specification | 4inputs,1output |
Cable | Specification | 10mm2 |
Solar Mounting System | Pitch/Flat Roof/Ground Mounting Type | |
Package Data
Item Name | Description | Quantity |
Solar Panel | RSM72-156P-280 | 36pcs |
Inverter | OFF-grid inverter 10KW | 1pc |
Charge controller | 216V 50A | 1pc |
Battery | 12V 250AH | 18pcs |
Distribution Box | 4inputs,1output | 1pc |
Cable | pv cable 10mm2 | 400m |
Mounting system | Pitch Roof/Flat Roof/Ground Mounting | 10kw |
How does it work?
The term off-grid refers to not being connected to a grid, mainly used in terms of not being connected to the main or national electrical grid. In electricity, off-grid can be stand-alone systems (SHS) or mini-grids typically to provide a smaller community with electricity.
Complete Solar Power Off-Grid System Connection Diagram
