nickel iron battery australia 1.2v solar battery 1.2V 1000Ah

Product Overview

Description

Military quality standard long life NiFe Solar storage battery 1.2V1000Ah

Voltage: 1.2V

Capacity: 1000Ah



PE	MAX. DIM(mm)			Max. weightv(not filled) (kg)	Max.weight (filled) Kg	Casing Material	Terminal
Length (L)	Width (W)	Hight (H)
OPNF10	38	84	128	0.6	0.7	PP/MBS	M6
OPNF17	32	113	223	0.9	1.2	PP/MBS	M6
OPNF20	32	113	223	1	1.2	PP/MBS	M6
OPNF22	32	113	223	1.1	1.25	PP/MBS	M6
OPNF25	32	113	223	1.15	1.3	PP/MBS	M6
OPNF30	68	134	245	1.7	2.55	PP/MBS	M10X1
OPNF40	68	134	245	2.1	2.85	PP/MBS	M10X1
OPNF45	68	134	245	2.4	3	PP/MBS	M10X1
OPNF50	68	134	245	2.5	3.2	PP/MBS	M10X1
OPNF60	68	134	245	3.2	3.6	PP/MBS	M10X1
OPNF70	80	141	370	3.8	5.7	PP/MBS	M10X1
OPNF80	80	141	370	4	5.8	PP/MBS	M10X1
OPNF90	80	141	370	4.2	6	PP/MBS	M10X1
OPNF100	80	141	370	4.5	6.2	PP/MBS	M10X1
OPNF115	80	141	370	4.9	6.3	PP/MBS	M10X1
OPNF120	80	141	370	5	6.5	PP/MBS	M10X1
OPNF125	53	190	402	6.5		PP	M10X1
OPNF130	80	141	370	5.3	6.5	PP/MBS	M10X1
OPNF135	92	141	365	6	7.8	PP	M16X1.5
OPNF140	92	141	365	6	8	PP	M16X1.5
OPNF150	106	164	345	7	9	PP/MBS	M20
OPNF165	106	164	345	7.2	9.5	PP/MBS	M20
OPNF180	106	164	345	7.5	10	PP/MBS	M20
OPNF200	106	164	345	8	11	PP/MBS	M20
OPNF230	164	167	345	9.5	13	PP/MBS	M20
OPNF250	100	170	450	11	13.5	PP	M20
OPNF250	138	276	420	13	18.5	PP/MBS	2xM16
OPNF300	138	276	450	14.5	20.5	PP/MBS	2xM16
OPNF320	138	276	490	16	26.5	PP	2xM16
OPNF340	162	200	450	15.5	22	PP	2xM16
OPNF350	138	276	450	16	21	PP/MBS	2xM16
OPNF365	138	276	450	16.5	22	PP/MBS	2xM16
OPNF400	138	276	450	17	23	PP/MBS	2xM16
OPNF420	138	276	450	18.5	24	PP/MBS	2xM16
OPNF450	138	276	450	19.5	24.5	PP/MBS	2xM16
OPNF500	138	276	490	20	27	PP	2xM16
OPNF600	176	291	510	27	37.5	MBS	2xM20
OPNF700	176	291	510	29	39	MBS	2xM20
OPNF800	186	398	570	39	59	MBS	3xM20
OPNF900	186	398	570	41	60	MBS	3xM20
OPNF1000	186	398	570	44	61	MBS	3xM20
OPNF1100	186	398	570	46	63	MBS	3xM20
OPNF1200	186	398	570	49	66	MBS	3xM20





  Characteristic

• Excellent charging efficiency and smooth discharge voltage
• High reliability without sudden death
• Ability to withstand ultra-high and ultra-low environmental temperatures
• Withstand physical and mechanical abuses
• Exceptionally long & reliable service life
• Pollution-free,total green energy
• low Self-discharging
• No emission of corrosive gases, Safe from flame & explosion
• Pollution-free and excellent mechanical strength
• Convenient for installation and low maintenance
• Comply with SGS and GOST standard.
• Availability to design and manufacture other model according to user's requirements



NF series solar NiFe batteries are suitable for all solar photovoltaic power systems. They are widely used as storage power supply for solar photovoltaic systems, offshore oil platforms, railway transportation, crossing guards lighting, signaling, isolated BTS station, cathodic protection for pipelines and radio navigation systems.

NF series solar Ni-Fe batteries can last longer than 20 years if they are operated with the commercial and residential buildings recommended practice.

Benefits of NF series NiFe Battery:

1. Environmental friendliness(no lead, cadmium, or acid and is highly recyclable).

2. Long cycling life(Maximum service life can reach 20 years or more, if operated correctly).

3. Able to withstand abuse and wide temperature variation.

4. Resistant to withstand failure of electronic control systems.

5. Higher charge ratio and utilization ratio.

6. Low transportation and installation cost.

7. Low maintenance.

NIFE battery for Photovoltaic Applications:

Effect of temperature on performance:

Cycling:



Effect of Temperature on Lifetime(compare with lead acid battery):
