Renjiang 24 hours working Industrial off grid 8KW solar sun energy panel sources of energy

Product Overview

Description

Renjiang Industrial off grid 8KW solar panel system for 24 hours working time system



  1>  Product Description



Off-Grid 8000w Solar Power System Technical Data

Item No.		RSM8000-OFF
Capacity		8120VA
Daily power consumption		Solar radiation 3-5 hours 24KWH-40KWH
System voltage		96V
Solar panel	Type	RSM72-156P-290
	Pmax	290W
	Vmp	36.39V
	Imp	7.97A
Inverter	SPEC.	8KW
	Wave form	Pure sine wave
	Output voltage	AC110V/220V
	Output Frequency	50Hz/60Hz
	Inverter Efficiency	90%
Controller	Rated voltage	96V
	Rated current	90A
	Control mode	PWM
	Protection	Reverse polarity, overload, reverse charge,etc.
Battery	Battery Type	Sealed Gel
	Voltage	2V
	Capacity	400AH
Distribution Box	Specification	7inputs,1output
Cable	Specification	16mm2
Solar Mounting System		Pitch/Flat Roof/Ground Mounting Type





                    Package Data

Item Name	Description	Quantity
Solar Panel	RSM72-156P-290	28pcs
Inverter	OFF-grid inverter 8KW	1pc
Charge controller	96V 90A	1pc
Battery	2V 400AH	48pcs
Distribution Box	7inputs,1output	1pc
Cable	pv cable 16mm2	400m
Mounting system	Pitch Roof/Flat Roof/Ground Mounting	8kw









How does it work?

  The term off-grid refers to not being connected to a grid, mainly used in terms of not being connected to the main or national electrical grid. In electricity, off-grid can be stand-alone systems (SHS) or mini-grids typically to provide a smaller community with electricity.







Complete Solar Power Off-Grid System Connection Diagram









 More solar system information please click:

1kw 2kw 3kw 4kw 5kw 6kw 7kw 9kw 10kw



   2> Product line







   3> Packaging & shiping









   4>  Payment Terms





T/T, L/C are the payment methods we allow at this time.



   5>  Company Information



  Jiangxi Renjiang Technology Co.,Ltd

      · Renjiang is specialized in solar system research and developing, producing and marketing.

      · Our company is located in Pingxiang of Jiangxi Province.

      · With internationally advanced production equipment, exquisite technical processes and a

        strict quality control system.

      · All products are approved by ISO9001/14001, TUV, UL, CE& CSA.

      · Renjiang has powerful Research Ability, 15~20 new kinds of products are launched each

       year.

      · Renjiang has annual 200MW solar panel and solar cell production capacity.



Show Room & Office





Certificate Of Renjiang



 Guangzhou Fair





  6>  Our Services





Why do you choose us?



1.Reply your inquiry in 24 working hours



2.Customized design is available, OEM is welcomed



3.Delivery the goods to our customer all over the world with speed and precision



4.Offer the customer the lowest price with high quality solar modules



                High efficiency, high safety, high reliability



  7>  FAQ



1. Q: Do you have your own factory?

    A: Yes, we have. Our factory located in Pingxiang city, Jiangxi province.



2. Q: Is your products the lowest price?

    A: Ex-factory price, the same quality, we are much cheaper than other suppliers.



3. Q: Could you print our company LOGO on the nameplate and package?

    A: Yes, we can do that.



4. Q: Do you accept custom design on size?

    A: Yes, if the size is reasonable.



5. Q: Can we design packaging?

    A: Yes, default is regular packing, we can make customer’s own packing.
