Onekin MgO lightweight prefabricated hollow core partition drywall internal external fascias soffits tile backing panel
- Category: >>>
- Supplier: Chengdu Onekin Green Building Materials Co. Ltd.
Share on (60333929544):
Product Overview
Description
Product Description
Onekin Green Panel is a Magnesium Oxide based, non-toxic and environmental friendly
new technology constructional and decorative product.
Onekin Green Panel is stronger, more popular than other ordinary sheathing constructional
products. Thanks to its high flexural and compressive strength, as well as impacting strength,
yet, due to its impressive performances triggered by other characteristics, such as fire resistance,
thermal conductivity, acoustic reduction and heat insulation, Onekin Green Panel can fully match
every modern demand of almost all constructional and decorative applications, including wall
partition, ceiling linings, floor underlayments, fascias, soffits, and tile backing.
During the whole producing procedure, no toxic additives, asbestos, formaldehyde, hazardous
elements or excessive waste was added at all. Also only very little amount of CO2 will emit into
atmosphere during production.
Besides,when the construction needs to be removed, the remaining residues can still be completely
recycled, for Onekin Green Panel itself is absolutely natural. Its production mostly rely on self reaction between Magnesium Oxide and Magnesium Chloride.
Therefore, Onekin Green Panel can be called a brand new and ideal constructional products enhance not only buyers’ requirements, but also the expectations of new century.
Technical Data
Advantages
Lighter weight | ü 36kg/m2 for 90mm thickness, only around 1/3 that of cement board; ü Faster and easier installation, 40m2/worker/day; ü Shorter project period, less labor and materials cost; ü Up to 30% total project cost reduction. |
Higher flexural, compressive and impacting strength | ü Less wastage during transportation, handling, installation and decoration; ü Ideal for adding fireproofing to wood, masonry or steel frame construction; ü Convenient for all other wall partition cladding process. |
Higher fire resistance and non-combustibility | ü Class A according to national standard; ü No flame spread or hazardous smoke developed according to ASTM test method; ü Non-combustible at 800℃, no flame at 1200℃ according to national standard; ü Refractory material for infrared radiation to save energy. |
Lower thermal conductivity but higher heat absorption | ü Heat absorption up to 80%; ü Creating a nicer living environment. |
Mineral based and stronger stability | ü Longer endurance, less cost on re-decoration; ü Subjected to temperature change; ü No expansion or contraction; ü Reduce allergies coursed by acid or alkali in experiment, laboratory, school, hospital and factory; ü Termite and other insects resistance; ü Lower moisture infiltration; ü Mold and mildew resistance. |
Superior sound insulation | ü 36 to 51 dB by national standard. |
Completely natural and environmental protection | ü Production mostly rely on self-reaction of raw materials; ü No toxic additives; ü Free of asbestos, formaldehyde or radiation; ü 100% Bio-degradable and recyclable; ü Produced without excessive waste; ü Very little amount of CO2 emitted during production. |
Applications
u Residential, Commercial, Industrial, Institutional and entertainment construction ;
u Internal and external non-bearing wall partition ;
u Kitchen, bathroom and toilet ;
u Roof tiles or floor underlayment.
Packaging & Shipping
Length: 2200-3600 mm
Width: 600 mm
Thickness: 75/90/100/120/150/200 mm
Standard size: 2800x600 / 2900x600 mm, customerized dimensions available
Dimension (mm) | Avg. surface density (kgs/m2) | Packing quantity FCL 40'HQ (pcs) |
| 2800x600x75 | 33 | 440 |
| 2800x600x90 | 36 | 400 |
| 2800x600x100 | 40 | 352 |
| 2800x600x120 | 45 | 300 |
| 2800x600x150 | 53 | 240 |
| 2800x600x200 | 70 | 168 |
Installation process
FAQ
01. What is Onekin Green Panel?
Onekin Green Panel is kind of inorganic building materials, the main theory is that magnesium oxide reacts and bonds with magnesium chloride, filling material is fly ash and reinforced by plant fiber. The main applications of Onekin Green panel are wall partitions to take places of clay bricks, hollow block, cement hollow panel.
02. How are Onekin Green Panels priced?
Onekin Green Panel pricing is depending on several variables:
Proper panel thickness;
Suitable panel sizes;
Internal panel structural requirements;
Below grade/above grade considerations;
Site planning and foundation considerations.
03. How to install Onekin Green Panel?
T & G joins, easy for installation and connection between two panels, or panel and column. Using U shape clips, the same for ceiling and floor part, for details installation method. Customer can get full instruction of Grenn Panel installation after the purchase.
04. The water saturation effect Onekin Green panel?
Although Onekin Green Panel does not absorb much water or moisture in natural circumstances, it is still recommended to use coated fasteners on specific increments, as well as using protective measures to eliminate water penetration.
Our Services
- Committed to quality and pursue customer satisfaction by delivering world-class quality products and services through continuous improvements and innovations.
- Quality Management System includes:
- Pre-Production inspection for raw materials
- In-Process quality control
- Pre-shipment loading inspection
- Strong system for traceability on our products.
