Tyre Punger Test Equipment DW5920
- Category: >>>
- Supplier: Hefei Fanyuan Instrument Co. Ltd.
Share on (60335190713):
Product Overview
Description
Application:
DW5920 tyre punger test equipment is widely used in world famous tyre manufactures and national rubber tyre quality inspection center (Government Organization) for inspecting tyres.
Related Standards:
STANDARDS | ASTM F414/870 | ISO 10191/10454 | JIS D4230 |
Note: this tire tyre punger test equipment can conform to but not limit to all the standards above, for more standards conformance, please contact us.
Key Specification:
| Load cell | 2000kgf, 5000kgf, 10000kgf (can be customized) |
| Accuracy of load cell | ±0.04% of max. capacity |
| Measurement accuracy | in accordance with ISO10191 |
| Force | ±0.5%F.S. |
| Speed & displacement | ±1%F.S. |
| Motor | AC brushless servo motor (hydraulic system optional) |
| Plunger stroke | 700mm |
| Max. tyre outer diameter | |
| plunger test | 1500mm |
| bead unseating test) | 900mm, 0-205mm in width |
| vertical stiffness test, lateral stiffness test and footprint analysis | 1500mm |
| Test speed | 0~200mm/min±1.0mm, adjustable |
| Plunger size | 8mm, 19mm, 25mm, 32mm and 38mm (please choose two pcs) |
| Bead unseating block | in accordance with DOT FMVSS No. 109 or JIS D4230. load block (choose one) |
