Соединяющиеся Тротуарные бетонные блоки/кирпичная мощение

Product Overview

Description

interlocking pavements concrete blocks /brick paving

Water permeable bricks use the slag waste and waste ceramics as raw materials, which is the preferred product used to beautify the city, improve the quality of living environment.



1. Water Permeable Bricks Information

01) The product Colors





02) The product Specification

Materials	1)   The slag waste 2)   The waste ceramics
Size	1)   300*300*55mm (50mm, 40mm, 30mm) 2)   150*300*55mm (50mm, 40mm, 30mm) 3)   200*200*55mm (50mm, 40mm, 30mm) 4)   200*100*55mm (50mm, 40mm, 30mm)
Color	Brown, Pink, Yellow, Black, Grey, White Also it can as per customs' requirements.
Application	City road, The parks, Villas, Residential quarters, Landscape and Garde decoration etc.
Function	Good water permeability, Function of automatic adjustment, Noise reduction, High compress strendth, Low carbon emission and enviromental protection etc.
Delivery Time	About 10-20 days after receiving the deposit
Payment Terms	T/T, L/C
Packing	Put a layer of foam cloth between each 2 panels, cover the whole pallet with foam cloth, use hard paper to protect angles, and roll the whole pallet with thin film. The customers’ demands also could be accepted.





03) Certificate Awarded





04)The performance of products test

Product Index
Items of test	Product performance
Water absorption rate(%)	Mean value≤0.5
Water permeability(mm/s)	Mean value≥20
Rupture modulus(Mpa)	Mean value≥35, single value≥32
Anti-skid(BPN)	Mean value 65-85
Frost resistance(℃)	Mean value≥(-25)
Breaking strength(N)	Thickness≥7.5mm, mean value≥1300N
Side length deviation(%)	±0.6
Thickness deviation(%)	±5
Central curvature(%)	±0.2
Side straightness(%)	±0.3
RIGHT ANGLE	±0.3
SURFACE FLATNESS(%)	±0.15
SURFACE QUALITY	No visible defects judging from  the point where is 80cm distance upright the tile
Wearing capacity(mm)	≤140
Resistance to thermal shock	Eligible
Resistance to clazing	Eligible
Resistance to pollution	Eligible
RESISTANCE TO HOUSEHOLD CHEMICAL REAGENT	Eligible
RESISTANCE TO SWIMMING POOL ALKALI	Eligible



2. Water Permeable Bricks Advantages

Water permeable bricks have a lot of advantages, such as good water permeability, water retention, skid resistance, noise reduction, repeated use, compression-resistant, cold-resistant and weathering-resistant etc.







3. Water Permeable Bricks Installation

4.Projects Cases



 A.  City Road



B. Side Walk





C. Park road



D. Swimming Pool



E. The plaza



F: The Bathroom



5. Water Permeable Bricks packaging & shipping









7. Company Information

    Xiamen Zhongjingtai Building Materials Co., Ltd is a large high-tech enterprise integrating scientific research, development, production and is currently the largest professional company in production, research and development of ecological water permeable ceramic bricks. ZJT ecological water permeable ceramic brick is developed by our company to solve the “Urban heat island effect” and increase surface hardening, to prevent city waterlogging and create high-quality natural environment as well as maintain ecological balance of the city.

    This product uses the slag waste, waste ceramics as raw material. After two times of material molding, high temperature sintering, the environmental product is produced with characteristics of keeping the ground water permeability, preserving moisture, compression-resistant, slip-proof, high strength, cold resistance, weather resistance, noise reduction, sound absorption and reusability. ZJT ecological water permeable ceramic brick is the preferred product used to beautify the city, improve the quality of living environment, and can be widely used in the building of public square, city road, subway, station, highway, villas, residential quarters, parks, landscape, garden decoration, kitchen space, etc.

    ZJT ecological water permeable ceramic brick passes the test of national quality testing center, which is the recommended product for key projects and green building materials product. Its performance indicators have reached or exceeded that of similar foreign products( the products in 2006 won the national invention patent and Third-place Prize of Jiangxi Province Technology Invention). It is a leading international product.



8. Our Services

a. Your inquiry related to our products will be replied in 24 hours.

b. Well trained and experiences staffs to answer all your enquiries in fluent English.

c. Any your customized items we can help you to design and put into production.

d. Protection of your sales area, ideas of design and all your private information.

e. Excellent quality and competitive price.

f. Best after-sale service.



 8. Company Contact Information



If any problem, pls don't hesitate to contact us,  the contact information as following:



Contact Person: zoe zeng

Telephone: 0086-592-5216902

Mobile Phone: 8618559217326
