Product Overview
Description
Products Description
Focus On Time Control For 24 Years
Description:
- Small universal relay capable of power switch
- Applications
Switch control for electric tools and a variety of motor
Switch control for a variety of drying machine power control
Switch control for controlling various lights
Switch control for packaging machines, food processing equipment power control
- Low power consumption
- Rugged Design
- Silver alloy contacts
- Multiple type relay
MY4:Standard models
MY4-S: With manual test button function
MY4-N: With operation indicators
MY4-F: With flange
MY4-D: With built-in diodes
MY4-O: With PCB Terminals
- Power Supply
AC(V) 6,12,24,48,60,110,220,240,380 50Hz
DC(V) 6,12,24,48,60,110,220
- Output Contacts rated 5A at 250 VAC or 30 VDC
- Four pole changeover contacts
- Socket mounted with a PTF14A/ PTF14A-E Socket(Except MY4-O)
- Small universal relay capable of power switch
- Applications
Switch control for electric tools and a variety of motor
Switch control for a variety of drying machine power control
Switch control for controlling various lights
Switch control for packaging machines, food processing equipment power control
- Low power consumption
- Rugged Design
- Silver alloy contacts
- Multiple type relay
MY4:Standard models
MY4-S: With manual test button function
MY4-N: With operation indicators
MY4-F: With flange
MY4-D: With built-in diodes
MY4-O: With PCB Terminals
- Power Supply
AC(V) 6,12,24,48,60,110,220,240,380 50Hz
DC(V) 6,12,24,48,60,110,220
- Output Contacts rated 5A at 250 VAC or 30 VDC
- Four pole changeover contacts
- Socket mounted with a PTF14A/ PTF14A-E Socket(Except MY4-O)
Type | MY4 |
Dimensions(mm) | 27.5×21.5×35 |
Contact form | 4Z |
Contact capacity | 5A at 250 VAC or 28 VDC |
Coil voltage | AC(V) 6,12,24,48,60,110,220,240 50Hz |
DC(V) 6,12,24,48,60,110,220 | |
Coil power | DC:≤ 0.9W AC: ≤ 1.2VA |
Pick-up | DC:≤ 75% AC: ≤ 80% |
Drop-out | DC: ≥10% AC: ≥ 30% |
Contact resistance | ≤ 50mΩ |
Resistance insulation | ≥ 100MΩ(DC 500V) |
Life | Electrical 1*105times |
Mechanical 5*106 times | |
Dielectric strength | Between open contacts :1000VAC rms |
Between coil & contacts :1500VAC rms | |
Mounting form | PCB & Socket |
Ambient temperature | -25℃~+55℃ |
Weight | 35g |
Fitted socket | PYF11A,PYF14A-E,PY14 |
