Mini concrete mixer truck 6 cubic meters concrete mixer truck dimensions

Product Overview

Description

Feature of concrete mixer

1. The tank body uses double helical blades that makes its density moderate, with symmetrical mixing board on the front taper place; double blades and guiding blades of discharge are installed on the outlet of tank, which makes the discharge more evenly, faster in speed, and convenient for the pumping transportation of other devices (such as automobile pump).

2.The tank body adopts the domestic first submerged arc welding technology which makes it more solid in strength and more beautiful in appearance. The linked parts of the tank body use bounded construction which can extend its service life. The seal head adopts German cold spinning technology that makes it sleek and fine in appearance. And six reinforcement plates are installed inside the seal head and can increase its wear resistance.

3.Low angle for mixing drum can extend the service life of hydraulic pump, motor and reducer. The sub frame uses high intensity square tube with damping in the central area that can play role when vehicle is at full load and under the bad conditions of road, which can lower the center of gravity of truck and make it move more smoothly.

4. The upload production of this mixer adopts multiple advanced technology, which can produce various types of mixer in volume such as 8CBM, 9CBM, 10CBM, 12CBM, 14CBM, 16CBM.





Main technical parameters



Model	Mixing drum capacity(m3 )	Chassis model	Air-conditioner	Gear box	Tire	Engine	Power (KW)	mixing system
CLCMT-12A	12	SX5255GJBJR404(Delonghi)	YES	nine speed	Meridian tire	WP10.336	250	Italy Bonfiglioli or PMP speed reducer; American Eaton or Italy PMP hydraulic systme
CLCMT-12B	12	ZZ1257N4048W (HOWO)	YES	ten speed	Meridian tire	WD615.95E	250
CLCMT-10A	10	SX5255GJBJR404(Delonghi)	YES	nine speed	Meridian tire	WP10.336	250
CLCMT-10B	10	ZZ1257N3847 (HOWO)	YES	ten speed	common tire	WD615.95E	250
CLCMT-9	9	EQ1250GFJ3 (Dongfeng)	NO	nine speed	Nylon tire	YC6M290-33	215
CLCMT-8	8	EQ1250GFJ3 (Dongfeng)	NO	nine speed	Nylon tire	YC6M290-33	215
CLCMT-6	6	STQ512L5T43	NO	six speed	Nylon tire	YC6J190-33	140	Made in China
CLCMT-4	4	SXBF006E	NO	Fastre 8JS85E	Nylon tire	YC4D130-33	140	Made in China
