Automatic high speed 5 ply corrugated cardboard used complete production line for sale
- Category: >>>
- Supplier: Zhengzhou Dingchen Machinery Co. Ltd.
Share on (60345672546):
Product Overview
Description
Product Description
Automatic high speed 5 ply corrugated cardboard used complete production line for sale
This line is the newest model which is upgraded on base of our quondam automatic re-winder and foreign technology.
A lot of advanced control technology are used in this line,such as: Program Logic Control System;HMI,;one button chinese-english switch;synchronous frequency conversion drive;integration of mechanics,electrics and photo.It is equipped with whole trouble information.It can detect and adjust every action of the rewinder automatically to keep the rewinder in optimal situation.For example:There is a web tension system in the line,It can control speed according to the tension of web so it can adapt different type of jumbo roll.So it is the best choice to produce top-grade bathroom tissue and kitchen towel for paper company. The characteristics of the rewinder are as follows:
1,Unwind is equipped with closed loop frequency conversion control system.
2,When the webs do not align,you can operate on the touch button screen to move the jumbo roll till webs align.
3,When the core unit can not detect core or core will use up, the machine will alarm to tell operator or workers to put some cores on the core bracket.
4,When the machine is running, web break off suddenly for reason of speed change sharply of problem from jumbo roll.
5,Degree of tightness can be adjusted while a log is rewinding.It can produce different degree of tightness in one log.
6,When a log is rewinding,the next core is ready.
7,For the reason of using advanced technology:Program Logic Control System; synch-ronous frequency conversion drive;integration of mechanics,electrics and photo.
8,When the finished log come to tail sealer, trimming, glue spraying and sealing can be finished at the same time.
9,embossing unit and glue applicator,edge embossing unit,printing system is order by customer.
REWINDING SYSTEM
ITEM | 2900(other size to be specified) |
Jumbo roll width | 2850mm(other size to be specified) |
Jumbo roll diameter | ≤Φ2500-3000mm(other size to be specified) |
Jumbo roll core size | Φ76mm,shaftless type(to order) |
Finished roll diameter | Φ90~Φ135mm |
Finished roll core diameter | Φ38~Φ50mm |
Perforation pitch | 90~160mm (other size to be specified) |
Perforation | 6PCS sprial upper perforation knives,improve the durability |
Rewind type | Non-stop |
Parameter set | HMI |
Coreless rewind | Vacuum suction(patent protection) |
Rewind alternation | Core insert(patent protection) |
Rewind system | With core and coreless integrated |
Control system | PLC,inverter,optical-electro-mechanic integration |
Tension control | Encoder,PLC,inverter |
Transmission | Gear,timing belt,flat belt |
Machine speed | 600m/min |
Alternation speed | 30logs/min |
Backstand | 1~3ply(to be confirm by client),independent drive |
Power | AC380V 50HZ motor and servo motor |
Pneumatic system | 0.5~0.8MPa(provide by client) |
T30 tail sealer | Patent protection |
Gluing system | Reciprocating type spray nozzle sealing, double channel |
speed | 30logs/min |
Tail length | 5-30mm adjustable |
Log diameter | Φ60-130mm |
Option: | |
Embossing unit | Steel to rubber,point to point/nested/DECO embossing lamination system |
Edge embossing unit | Steel to steel |
ACCUMULATOR
ITEM | 2900 |
Log diameter | 2850mm |
Log diameter | Φ90~Φ135mm |
Effective log Qty | 300logs |
Speed | 20 logs/min |
Power | 3KW |
LS160-4L Log saw
Log length | 1500mm-2700mm |
Log feed | Servo control feeding system |
Speed | 160cuts/min,4rolls/cut |
Feeding channel | 4channels |
Grinding system | Pneumatic grinding,parameter can be set on control panel |
Circular blade diameter | Φ610mm |
Cutting tolerance | ±1mm |
Log size | Φ90~135mm |
Dust suction system | Remove the tissue and grinding dust |
Control system | PLC |
Installation power | Main motor:15KW |
The process flowing chart:
Packaging & Shipping
Our Services
Our service
| Per-sales service | 1) sales person, project manager, accountant staff 2) professional responsible teem: would be very fastly and exactly to send you offers |
| Online/sale service | 1) super and solid quality 2) fastly delivery 3) standard export package or as you demand |
| After-sale service | 1) repairing and maintenance if any problem occur in the warranty 2) any feedback of machine can be told us, and we will try our best to support you |
Other cooperation service | 1) technology knowledge share 2) honest to customers |
1. One-year warranty and lifetime maintenance consult and spare parts order with discount
2.“Customer foremost, creating exquisite” is each Dingchen native’s ideal pursuit. You can enjoy DCj’s excellent services after you buy paper machine products.The sales staff of the franchised store listens to your opinions,answers your questions,offers you sincere suggestions and extends care to each corner of your factory.
3.Purpose of service is “dedication to customer service,installation,debugging,trail tasks”,each service must adhere to this principle,and are willing to accept the advice and supervision of the customer.Of the company’s products,for any quality problems during the trial,we committed to responsible for replacement and satisfy your special requirement until you feel satisfied.
4.In case of any quality problems within 1 year under customers’ regular use, we are responsible for repairing or replacing (repairing unavailable) with the same kind of the products. If the one-year warranty expires, we will charge costs in accordance with the unified charging standards based on specific situations.
Company Information
We Zhengzhou Dingchen machinery company limited has a history more than 30 years in producing pulp and paper making machines.Our products include paper making machines,pulp making machine,parts and paper converting machines such as kraft paper machines,corrugated paper machines,tissue/toilet paper machines,office paper machines, newspaper machines,and so on.Our factory gathers and trains many essential technicians and management system to ensure all products meet the quality of ISO and update constantly!
Our machines have been exported to many countries such as Uzbekistan,Pakistan,Syria,Jordan, Armenia,Yemen,Egypt,Sudan,Angola,Uganda,Nigeria,Tanzania,Gana,Brazil,Paraguay,Bangladesh, Fiji,Myanmar and so on. We win high praise from clients at home and abroad for our sophisticated craft, high quality and excellent function.
FAQ
1.What information do you need,if i need to get a quotation from you?
Answer:Output paper type;Capacity(tons/24hours);Output paper weight(gram/m2);Raw material.
2.How long is guarantee period for paper making machine?
Answer:12 months after formal operational
3.What is the delivery time if we make a order from you?
Answer:Usually,the delivery time for smaller machines is 30-45 days after receiving deposit,but for bigger
machines,it will be longer to make sure the equipment quality.
4.What is your payment terms?
Answer:(1). T/T(telegraphic transfer)30% as deposit,and 70%balance paid before shipment.
(2). 30%T/T + 70%L/C at sight. (3). 100%L/C at sight.
5.How is the quality of your equipment?
Answer:
(1).We have been specializing in pulp and paper making machines for 40 years.We have enough practice/experience.To keep and develop our good reputation,we couldn't allow the unqualified machine,as well as you.
(2).We have a technician team of engineers and experts.They mainly research the advanced paper making
technology,to make sure our machines’ design are newest.
(3). The machines will be pre-installed at workshop before delivery.
6.Why your price is higher than other similar supplier?
Answer:Different quality,different price.Our price is matched with our high quality.Compared with other suppliers
based on the same quality,our price is lower.But anyway,to show our sincerity,we will give you some discount.
